Research on SAFT Imaging Method of Array Probes in Concrete Structures

Abstract:

Because of the need of rapid detection of internal defects and embedded object in concrete structures, a detecting method with linear array probes is presented here, which is the high-resolution and efficient imaging technique for concrete structures by combining with synthetic aperture focusing technique (SAFT). Firstly, array simulation data are processed to be amalgamated B-scan data of concrete structures according to the structural characteristics of linear array; And then the B-scan data are reconstructed in the light of geometrical relation of ultrasonic path and SAFT; At last, the structural imaging figure are calculated. It can be shown from simulation results that the method is effective, and the embedded object in model can be identified effectively.

• Periodical: Applied Mechanics and Materials (Volume 189)
• Pages: 265-269
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.189.265
• Online since: July 2012
• Authors: Qiu Feng Li, Pang Huang, Yin Liao
• Keywords: Array Probes, Concrete Structure, SAFT, Ultrasonic Detection

References

[1] B.S. Sun, F. Zhang, J.Z. Shen. Synthetic Aperture Focusing in Time-domain for Acoustic Imaging. ACTA ACUSTICA, 1997, 22(1): 42-49.

[2] Li qiufeng, Shi Lihua, Liang Dakai. Study on 2D Imaging Technique for Concrete Cross Section Base on SAFT. ACTA Acoustic, 2008, 33(4): 370-377.

[3] Cai L., Lan C. Research on imaging method of synthetic aperture focusing. Journal of Wuhan University of Technology, 1996, 13(2)：18(1)：84-87.

[4] Sun B S, Shen J Z. Synthetic aperture focusing for ultrasonic imaging (part I). Applied Acoustics, 1993, 12(3)：43-48.

[5] Z. Hosseini, M. Momayez, F. Hassani, and D. Lévesque, Detection of inclined cracks inside concrete structures by ultrasonic SAFT. Review of Progress in Quantitative Nondestructive Evaluation, 2008, (27), pp.1298-1304.

DOI: 10.1063/1.2902583

[6] M. Schickert. Ultrasonic NDE of Concrete. Proc. of 2002 IEEE Ultrasonics Symposium, München, 2002, NY: Institute of Electrical and Electronics Engineers (IEEE), 2002: 718-727.

DOI: 10.1109/ultsym.2002.1193506

[7] M. Krause, B. Milmann, F. Mielentz, D. Streicher, B. Redmer, K. Mayer, K. -J. Langenberg, M. Schickert: Ultrasonic Imaging Methods for Investigation of Post-tensioned Concrete Structures: A Study of Interfaces at Artificial Grouting Faults and Its Verification. Journal of Nondestructive Evaluation, Special Issue on Acoustic and Electromag. Nondestr. Eval. of Concrete Structures, 27 (2008).

DOI: 10.1007/s10921-008-0033-5

[8] J.F. Chaix, V. Garnier, G. Corneloup. Ultrasonic Wave Propagation in Heterogeneous Solid Media: Theoretical Analysis and Experimental Validation. Ultrasonics, 2006, 44(2): 200-210.

DOI: 10.1016/j.ultras.2005.11.002

[9] P. P. Delsanto, S. Hirsekorn, A Unified Treatment of Nonclassical Nonlinear Effects in the Propagation of Ultrasound in Heterogeneous Media. Ultrasonics, 2004, 42(1): 1005-1010.

DOI: 10.1016/j.ultras.2003.12.019

[10] M. Schickert, M. Krause, W. Müller, Ultrasonic Imaging of Concrete Elements Using Reconstruction by Synthetic Aperture Focusing Technique. Journal of Materials in Civil Engineering 15 (2003) 235–246.

DOI: 10.1061/(asce)0899-1561(2003)15:3(235)

[11] Li Qiufeng, Shi Lihua., Jin Xinhong. Study on an improved SAFT algorithm. PIEZOEL ECTECTRICS & ACOUSTOOPTICS, 2009, 31(3): 440-443.

[12] Jianhua Tong, Chinlung Chiu, Chungyue Wang, Improved synthetic aperture focusing technique by HHT for imaging defects inside a concrete structure, IEEE Transactions on ultrasonics, ferroelectrics, and frequency control, 2010, 57(11): 2512-2521.

DOI: 10.1109/tuffc.2010.1717
