Application of FPGA-Based Large-Screen and High-Resolution Display Accelerator in Computerized Flat Knitting Machine

Abstract:

In this paper, the application of a FPGA-based large-screen and high-resolution display accelerator technology in full-automatic textile machinery (computerized flat knitting machine) is studied. The design of traditional computerized knitting machine system is difficult to support the display of large screen and high resolution operating interface. Therefore, a displaying accelerator is designed in this paper. It comprises of FPGA, configuration chip, SDRAM and LVDS transmitter chip, is located between the embedded main processor and high resolution TFT LCD screen of computerized flat knitting machine, and implements the modules such as display acceleration logic and SDRAM controller relying on Verilog HDL programming in FPGA. The computerized flat knitting machine, applying displaying acceleration technology, can present its dynamic color interface on an 800 x 600 resolution TFT LCD (10.4") on the condition that real time, reliability and cost can be ensured.

• Periodical: Applied Mechanics and Materials (Volume 192)
• Pages: 318-322
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.192.318
• Online since: July 2012
• Authors: Ji Ye Huang, Ming Yu Gao, Heng Cai
• Keywords: Computerized Flat Knitting Machine, Display Acceleration, Field-Programmable Gate Array (FPGA), Hangzhou Dianzi University, SDRAM Controller, TFT LCD

References

[1] Kai Deng, Yongming Wang. A Simple Method for SDRAM Controller. Foreign Electronic Measurement Technology, 2011 (09).

[2] Yizhuang Xie, Teng Long. FPGA-based Three-port Non-opaque SDRAM Controller. Microcomputer Information, 2010 (05).

[3] Ruxi Lu. The Design of Full-digital and Ultrahigh Resolution Display Processing System. Microcomputer Information, 2010 (30).

[4] Yanle Zang, Wenjun Zhu, Jie Lei. The Structure and Development of Domestic Computerized Flat Knitting Machine Control System. Journal of Xi'an Polytechnic University, 2011 (11).

[5] Wen Gao, Tuanshan Zhang, Dayue Zhu. Design of the Control System for the Computerized Flat Knitting Machine Based on the ATmega128 and FPGA. Programmable Controller & Factory Automation, 2009 (07).

[6] Lingjun Meng, Guobing Zhang, Hongtao Wang, Baogang Li. Application of LVDS Difference Interface Based on FPGA. Control and Instruments in Chemical Industry, 2010 (05).
