Design of a Traffic Detection System Based on Laser and Piezoelectric Technologies

Abstract:

This paper aimed to solve the problems that traffic detector which was used in china, can't satisfies the multifunction and high-accuracy needs of the domestic traffic survey and traffic volume measurement.We designed a traffic detection system based on laser and piezoelectric technologies,which is made up of laser speed sensor, laser scanning sensor, piezoelectric axle shaft sensor, data acquisition unit, software system and server, and their application was discussed in detail. The working principles of laser speed sensor, laser scanning sensor, piezoelectric axle shaft sensor were presented, and the detection parameters of the system were put forward. The whole structure and data processing flow of software system were also pointed out. Through test verification, the multifunction and high-accuracy characteristics of the system were verified. This traffic detection system has great significance for enhancing the research level of the domestic traffic survey and traffic volume measurement.

• Periodical: Applied Mechanics and Materials (Volumes 198-199)
• Pages: 1093-1098
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.198-199.1093
• Online since: September 2012
• Authors: Hong Qin Li, Li Wei Zhu, Zhi Yong Zhang, Cheng Zan Chu
• Keywords: Design, Laser Technology, Piezoelectric Technology, Traffic Detection

References

[1] Yin Chaozheng, Based on video virtual coil of traffic flow parameters testing, Beijing, Tsinghua University, 2002. 5.

[2] M.A. Green: High Efficiency Silicon Solar Cells (Trans Tech Publications, Switzerland 1987). Tong Jianjun, Zou Mingfu, Speed Measurement of Vehicle by Video Image, Journal of Image and Graphics, 10, 2005 (2): 192 ~ 196.

[3] Liu Cong, The Research of Application Problem For Vehicle Loop Detection System, " Guangdong, Zhongshan university master, s degree thesis, (2007).

[4] Sheng Dongpin, Liao Chuanjie, Xu Xinge, Chen Wenxiang, Application of Anisotropic Magnetoresistive Sensor for Vehicle Detection, Journal of Xiamen University(Natural Science), 48, 2009 (6) : 827~ 829.

[5] Duan Yibin, comprehensive compare of Highway traffic information collecting methods, China ITS Journal, 2006. 11.

[6] Zhu Liwei, Zhang Zhiyong, Wang Bin, Motor vehicle speed detector online calibration system, Journal of Highway and Transportation Research and Development, 10, 2007 : 33~ 35.

[7] An Fudong, Analysis of Several principle and performance of motor vehicle speed detection, Police Technology, 3, 2003 : 33~ 35.

[8] Shen Huan, Li Shunmin, Bo Fangchao, Liao Xiaodong, Li Fangpei, Lu Wenyu, On road vehicles detection approach using multi-cues fuse, Journal of Optoelectronics. Laser, 1, 2010 (21) : 74~ 77.

DOI: 10.3788/aos20103004.1076
