Design and Layout of a High-Performance PWM Control Class D Amplifiers IC Systems

Article Preview

Abstract:

This paper presents the design and implementation of a novel pulse width modulation control class D amplifiers chip. With high-performance, low-voltage, low-power and small area, these circuits are employed in portable electronic systems, such as the low-power circuits, wireless communication and high-frequency circuit systems. This class D chip followed the chip implementation center advanced design flow, and then was fabricated using Taiwan Semiconductor Manufacture Company 0.35-μm 2P4M mixed-signal CMOS process. The chip supply voltage is 3.3 V which can operate at a maximum frequency of 100 MHz. The total power consumption is 2.8307 mW, and the chip area size is 1.1497×1.1497 mm2. Finally, the class D chip was tested and the experimental results are discussed. From the excellent performance of the chip verified that it can be applied to audio amplifiers, low-power circuits, etc.
