A Connecting Method for Offset Contour of Planar Polygon

Abstract:

Triangular mesh is a digital representation mode widely used in CAD and CAM. And the connection of the offset vertexes is an important step in the edge isometry based polygon offset operation in path planning of layer milling complicated surfaces represented by triangular mesh. A vertex classification based connectiong method was presented. It avoids the vertex reflection, shortens the length of the contour and improves the performance of edge isometry based offset algorithm.
