Modeling and Optimization Research of a Planar Six Bar Mechanism

Abstract:

For being convenient for researching the dynamic characteristic and the improvement and use of the planar six bar mechanism, for improving the dynamic technical performance, the three-dimensional solid model of the mechanism was established with ADAMS. Each part of the model in ADAMS was set up. Simulation analysis on the working process of the mechanism was achieved. The structure optimization parameters of the mechanism were obtained. The result proves that the vertical location of revolute joint of link and rocker, the location of revolute joint of crank and frame, the horizontal locations of two revolute joints of link are almost no impact on the vertical speed of slider. The vertical locations of revolute joint of frame and rocker and revolute joint of block and slider have less impact on the vertical speed and acceleration of slider. The vertical location of revolute joint of link and crank, the horizontal locations of revolute joint of frame and rocker and revolute joint of block and slider have greater impact on the maximum vertical speed and acceleration of slider.

• Periodical: Applied Mechanics and Materials (Volumes 215-216)
• Pages: 921-925
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.215-216.921
• Online since: November 2012
• Authors: Ying Wu, Xu Zhou
• Keywords: Modeling, Optimization Research, Planar Six Bar Mechanism

References

[1] Guangjie Du. Design and Simulation of Actuator of Blank Holder Force Control by Servo Motor Direct Drive[D]. Yanshan University, 2011 . In Chinese.

[2] Kai-ping Yang, Yao-yao Shi, Li-ping Wang. Computer Simulation, Vo.l 28 No.5. 2011, pp.367-370, 383. In Chinese.

[3] Min-jie Wang, Hai-feng Yan, Ting Ge. Journal of North China Institute of Water Conservancy and Hydroelectric Power, Vol.32 No.5, Oct. 2011 , pp.102-104. In Chinese.

[4] Liqing Hao. The Shape Optimal Design of Bioprosthetic Heart Valve on Computer-Aided Industrial Design[ D].Shandong University ,2009. In Chinese.

[5] Yuemei Wu. The Study of Working Device of Underground Loaders Based on Virtual Design [D]. Hebei University of Engineering, April,2011. In Chinese.
