Study on Dynamic Performance of Linear Direct Drive Based on Pole Placement

Abstract:

Permanent magnet linear synchronous motors (PMLSM) can serve as direct drive actuators for machine tools. However, PMLSM is more easily affected by load disturbance, force ripple and parameter variation. As a result, the design of an appropriate controller and research on dynamic performance are very important for PMLSM. In this paper, a feedback controller based on pole-placement is proposed to achieve desired tracking performance. The effectiveness and feasibility of the proposed method are demonstrated through theoretical analysis. The dynamic response and disturbance rejection ability for linear servo system were researched and the parameters which influence the dynamic performance of the system were discussed.

• Periodical: Applied Mechanics and Materials (Volumes 215-216)
• Pages: 926-929
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.215-216.926
• Online since: November 2012
• Authors: Chao Pan, Jian Min Zuo, Mu Lan Wang
• Keywords: CNC Machine Tool, Dynamic Performance, Linear Direct Drive, Pole Placement

References

[1] S.Gordon, M.T. Hillery: J of Material Processing Technol.Vol.166(2005),p.321.

[2] A.T. Elfizy, G.M. Bone and M.A. Elbestawi: Int J of Machine Tools & Manuf. Vol.44(2004),p.465.

[3] J.M. Zuo, C.Pan, M.L. Wang and W.Su: 2010 Int Conf on Computer, Mechatronics, Control and Electronic Engineering(CMCE).Jilin,China.

[4] F.J. Lin, P.H. Shen and Y.S. Kung:IEEE Transactions on Magnetics.Vol.12(2005),p.4401.

[5] S.H. Xiao, C.L. Zha: Proceeding of the first int conf on innovative computing, information and contro(ICICIC'06). Beijing,China.

[6] M.T. Yan, Y.J. Shiu: Int J of Machine Tools & Manuf.Vol.48(2008),p.388.

[7] C.Feng, J.Kuo and C.H. Hsu: Int J adv Manuf Technol.Vol.28(2006),p.942.

[8] H.M. Hasanien, S.Muyeen and J.Tamura: 2009 IEEE Bucharest Power Tech Conference. June 28th-July 2nd,Bucharest,Romania.

[9] J.Y. Yen, H.M. Chang: Int J of Machine Tools & Manuf.Vol.44(2004),p.523.
