Robust Process Design towards through-Silicon via Quality Improvement Based on Grey-Taguchi Method

Abstract:

The robust design of chemical etching parameters is dealing with the optimization of the through-silicon via (TSV) roundness error and TSV lateral etching depth in the etching of silicon for laser drilled TSVs. The considered wet chemical etching parameters comprise the HNO₃ molarity, HF molarity, and etching time. Grey-Taguchi method is combining the orthogonal array design of experiments with Grey relational analysis (GRA), which enables the determination of the optimal combination of wet chemical etching parameters for multiple process responses. The concept of Grey relational analysis is to find a Grey relational grade, which can be used for the optimization conversion from a multiple objective case to a single objective case. Also, GRG is used to investigate the parameter effects to the overall quality targets.

• Periodical: Applied Mechanics and Materials (Volumes 217-219)
• Pages: 2183-2186
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.217-219.2183
• Online since: November 2012
• Authors: Chao Wei Tang, Li Chang Chuang, Hong Tsu Young, Mike Yang, Hsueh Chuan Liao
• Keywords: Chemical Etching, Grey-Taguchi, Optimization, Robust Design

References

[1] N.L. Ranganathan, E. Liao, L. Linn, W.S. Lee, Vincent, O.K. Navas, V. Kripesh, N. Balasubramanian, Integration of high aspect ratio tapered silicon via for silicon carrier fabrication, IEEE Trans. Adv. Packag. 32 (2009) 62–71.

DOI: 10.1109/tadvp.2008.2003350

[2] Y.H. Lee, K.J. Choi, Analysis of silicon via hole drilling for wafer level chip stacking by UV laser, Int. J. Precision Eng. Manuf. 11 (2010) 501–507.

DOI: 10.1007/s12541-010-0055-7

[3] B. Tan, K. Venkatakrishnan, Nd-YAG laser microvia drilling for interconnection application, J. Micromech. Microeng. 17 (2007) 1511–1517.

DOI: 10.1088/0960-1317/17/8/013

[4] B. Tan, Deep micro hole drilling in a silicon substrate using multi-bursts of nanosecond UV laser pulses, J. Micromech. Microeng. 16 (2006) 109–112.

DOI: 10.1088/0960-1317/16/1/015

[5] K. Venkatakrishnan, B. Tan, Interconnect microvia drilling with a radially polarized laser beam, J. Micromech. Microeng. 16 (2006) 2603–2607.

DOI: 10.1088/0960-1317/16/12/013

[6] C. W. Tang, H. T. Young, K. M. Li, Innovative through-silicon-via formation approach for wafer-level packaging applications, J. Micromech. Microeng. 22 (2012) 045019.

DOI: 10.1088/0960-1317/22/4/045019

[7] M. Steinert, J. Acker, M. Krause, S. Oswald, K. Wetzig, Reactive species generated during wet chemical etching of silicon in HF/HNO3 mixtures, J. Physics Chem. B. 110 (2006) 11377–11382.

DOI: 10.1021/jp0608168

[8] H. Robbins, B. Schwartz, Chemical etching of silicon I: the system of HF, HNO3, and H2O, J. Electrochem. Soc. 106 (1959) 505–508.

[9] H. Robbins, B. Schwartz, Chemical etching of silicon II: the system HF, HNO3, H2O, and HC2H3O, J. Electrochem. Soc. 107 (1960) 108–111.

[10] B. Schwartz, H. Robbins, Chemical etching of silicon III: a temperature study in the acid system, J. Electrochem. Soc. 108 (1961) 365–372.

[11] N. Tosun, Determination of optimum parameters for multi-performance characteristics in drilling by using grey relational analysis, Int. J. Adv. Manuf. Technol. 28 (2006) 450–455.

DOI: 10.1007/s00170-004-2386-y

[12] R. S. Pawade, S.S. Joshi, Multi-objective optimization of surface roughness and cutting forces in high-speed turning of Inconel 718 using Taguchi grey relational analysis (TGRA). Int. J. Adv. Manuf. Technol. 56 (2011) 47–62.

DOI: 10.1007/s00170-011-3183-z

[13] C. J. Tzeng, Y. H. Lin, Y. K. Yang, M. C. Jeng, Optimization of turning operations with multiple performance characteristics using the Taguchi method and Grey relational analysis, J. Mater. Process. Technol. 209 (2009) 2753–2759.

DOI: 10.1016/j.jmatprotec.2008.06.046

[14] J. Kopac, P. Krajnik, Robust design of flank milling parameters based on grey-Taguchi method, J. Mater. Process. Technol. 191 (2007) 400–403.

DOI: 10.1016/j.jmatprotec.2007.03.051

[15] Y. S. Tarng, S.C. Juang, C.H. Chang, The use of grey-based Taguchi methods to determine submerged arc welding process parameters in hardfacing, J. Mater. Process. Technol. 128 (2002) 1–6.

DOI: 10.1016/s0924-0136(01)01261-4
