Numerical Simulation on the Inner Flow Field of Ventilator Diffuser and Research on Energy-Saving

Abstract:

Ventilator diffuser with appropriate structure can improve the character of the diffuser . Building models of the log spiral diffusers of ventilator were classified and combined according to the length of post catheter, the condition whether the entrance bucket has been installed or not, and the length of the entrance bucket. Based on EFA software for hydrokinetics, the inner flow field of all combined diffusers were simulated and the related data were analyzed. In this way, graph of the static pressure coefficient (Cp), the atmospheric pressure coefficient (Cpa) and the diffuser efficiency (η) will be concluded under the work condition of every combination. By numerical analysis， an issue that the length of postpositive catheter, the condition whether the entrance bucket has been installed or not, and the length of the entrance bucket influent performance of the diffuser will be concluded. The issue studied would be a helpful reference for design to the log spiral diffuser of ventilator and for research on energy -saving.

• Periodical: Applied Mechanics and Materials (Volumes 220-223)
• Pages: 531-538
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.220-223.531
• Online since: November 2012
• Authors: Xiu Chuan Zhu
• Keywords: Efficiency, Energy Saving, Numerical Simulation, Pressure Coefficient, Ventilator Diffuser

References

[1] Geng-ying Chen. Energy saving and noise reduction of mine ventilator[M] .coal industry press. 1998(4) in Chinese

[2] kai Li.. FLUID MACHINERY, 2005(3): 1-4 in Chinese

[3] Wenke Li. engineering fluid mechanics[M],Hefei: China University of Science and Technology Press, 2007(2) in Chinese

[4] Robert LaMotte. Machine Elements in Mechanical Design[M]. Beijing：China Machine Press. 2008(8)

[5] Junqi Yan.mechanical design handbook[M].Beijing:machine industry press, 2000(6) in Chinese

[6] Renxi Hu, Jun Guo. advanced instance course on machine design based on Solidwords 2005[M], Beijing:machine industry press, 2005(1):145-153
