Research and Practice on New Measuring and Drafting Mode of Mechanical Drawing Based on Reverse Engineering

Abstract:

New mode of measurement and draft in mechanical drawing based on reverse engineering is presented to reflect the idea of modern engineering design on teaching practice. Traditional measurement tools are replaced by three-dimensional scanner, whereas graphics processing is performed by using CAD technology. The processing includes three steps. Firstly, point cloud of part surface shape is obtained through scanning. Secondly, point cloud images are joined, filtered and latticed in Geomagic, which is application software of CAD. Finally, the processed point cloud is imported into Catia to reconstruct surface and three-dimensional geometric model. An innovative method of measurement and draft is accordingly proposed, which combines teaching and practices and helps to cultivate the innovative idea and abilities of students.
