Identification of the Shape of Curvilinear Beams and Fibers

Abstract:

This work concerns the shape identification of curvilinear objects, for example bent beams or wires in mechanics. The beam’s digital picture is analyzed with the introduced Virtual Image Correlation method. This one consists in finding the optimal correlation between the beam’s image and a virtual beam, whose curvature field is described by a truncated series. The gray level and amplitude of the virtual beam does not need to reproduce exactly the ones of the physical beam image. The analytical form of the optimal shape allows one to derive mechanical properties: the identification of the Young’s modulus of a bar is given as an example. We will also show the robustness of the method with regards to the quality of the image.

• Periodical: Applied Mechanics and Materials (Volumes 24-25)
• Pages: 359-364
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.24-25.359
• Online since: June 2010
• Authors: Marc L.M. François, Benoit Semin, Harold Auradou
• Keywords: Analytical Shape, Curve Detection, Fiber, Filament, Loop, Virtual Image Correlation

References

[1] M. Gr´ediac, E. Toussaint, and F. Pierron. Special virtual fields for the direct determination of material parameters with the virtual fields method. 1-Principle and definition. International Journal of Solids and Structures, 39(10): 2691-2705, (2002).

DOI: 10.1016/s0020-7683(02)00127-0

[2] F. Hild and S. Roux. Digital image correlation: from displacement measurement to identification of elastic properties - a review. Strain, 42(2): 69-80, (2006).

DOI: 10.1111/j.1475-1305.2006.00258.x

[3] S. R. Aylward and E. Bulitt. Initialisation, noise, singularities, and scale in height ridge traversal for tubular object. IEEE Transactions on Medical Imaging, 21(2): 61-75, (2002).

DOI: 10.1109/42.993126

[4] M. V. D'Angelo, B. Semin, G. Picard, M. Poitzsch, J. -P. Hulin, and H. Auradou. Single fiber transport in a fracture slit: influence of the wall roughness and of the fiber flexibility. Transport in porous media, Published on line, DOI 10. 1007/s11242-009-9507-x, (2009).

DOI: 10.1007/s11242-009-9507-x

[5] E. M. Meacham and J. F. Doyle. Implementation of a versatile two-stage inverse solution method using non-linear image data. In Proceedings of the SEM 2007 conference, (2010).
