Parameterized Modeling and Dynamic Modal Analysis of Conjugate Cam Beating-up Mechanism

Abstract:

Taking the conjugate cams beating-up mechanism as an example to carry out three-dimensional parameterized design with Pro/Engineer secondary development accords to the equations of conjugate cams curves derived by the analytical method. Using the finite element software ANSYS the dynamic characteristic of beating rocker has been analyzed. And through the calculation the modal distribution and modal shapes of beating rocker are provided. It could provide references for design of future high-performance beating-up mechanism.

• Periodical: Applied Mechanics and Materials (Volume 251)
• Pages: 271-274
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.251.271
• Online since: December 2012
• Authors: Xue Mei Tang, Xin Xing Tang
• Keywords: ANSYS, Conjugate Cam, Modal Analysis, Parameterized Design, Pro/E

References

[1] Y.G. Shi and Z.H. Xu. Design of cam mechanism. Shanghai Science and Technology Press, (1995).

[2] S.H. Shen and X.L. Zhang. Computer-aided design of conjugate cam mechanism. Packaging engineering, 2005, 26 (1): 43-45.

[3] Q.S. Xie, S.B. Li and J.L. Chu. Finite element method in virtual prototyping. Journal of system simulation, 2003, 15(4): 508-515.

[4] Shi JianKui. Finite element modal analysis of vehicle engine connecting rod. Equipment manufacturing technology, 2009, 6.

[5] Y. Song, Y.Q. Ai and B. Liang. ANSYS7. 0 Finite Element Analysis. Beijing: Tsinghua University Press, (2003).
