Super-Harmonic Resonance Analysis on Torsional Vibration of Misaligned Rotor Driven by Universal Joint

Abstract:

The super-harmonic resonance of the nonlinear torsional vibration of misaligned rotor system driven by universal joint was studied considering both natural structure misalignment and actual error misalignment. Utilizing multi-scale method, the periodic solution of weakly nonlinear torsional vibration equation was obtained corresponding to super-harmonic resonance, including amplitude-frequency and phase-frequency characteristic expressions of steady periodic solution. The stability of equilibrium point was investigated using Lyapunov first approximate stability theory, then the stable region and unstable region on the amplitude of the super-harmonic resonance periodic solution, which varied with the detuning parameter. At last, the driving shaft’s steady periodic motion of the first approximation and its calculation simulation were carried out according to the kinetic relation about driven shaft and driving shaft. It is found that jumping phenomenon and dynamic bifurcation occur when the rotating angular velocity of driving shaft is half of the natural frequency of the deriving system. The results above indicate the fundamental characteristic of the nonlinear dynamic on the misaligned rotor, also applying the foundation for advanced bifurcation and singularities analysis.

• Periodical: Applied Mechanics and Materials (Volumes 26-28)
• Pages: 1226-1231
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.26-28.1226
• Online since: June 2010
• Authors: Chang Lin Feng, Yong Yong Zhu, De Shi Wang
• Keywords: Misaligned Rotor, Multi-Scale Method, Stability, Super Harmonic Resonance, Torsional Vibration

References

[1] B. Porter. A Theoretical Analysis of the Torsional Oscillation of a System Incorporating a Hooke's Joint. Journal of Mechanical Engineering Science, 1961, 3(4) , pp.324-329.

DOI: 10.1243/jmes_jour_1961_003_044_02

[2] B. Porter, R. W. Gregory. Nonlinear Torsional Oscillation of a System Incorporating a Hooke's joint. Journal of Mechanical Engineering Science, 1963, 5(2) , pp.191-200.

[3] S. I. Chang. Torsional Instabilities and Nonlinear Oscillation of a System Incorporating a Hooke's joint. Journal of Sound and Vibration, 2000, 229(4) , pp.993-1002.

DOI: 10.1006/jsvi.1999.2507

[4] S. F. Asokanthan, X. H. Wang. Characterization of Torsional Instabilities in a Hooke's Joint Driven System Via Maximal Lyapunov Exponents. Journal of Sound and Vibration, 1996, 194(1) , pp.83-91.

DOI: 10.1006/jsvi.1996.0345

[5] S. F. Asokanthan, P. A. Meehan. Non-linear Vibration of a Torsional System Driven by a Hooke's Joint. Journal of Sound and Vibration, 2000, 233(2) , pp.297-310.

DOI: 10.1006/jsvi.1999.2802

[6] ZHU Yong-yong, WANG De-shi, FENG Chang-lin. Nonlinear Analysis on Torsional Vibration of Misaligned Rotor Driven by Universal Joint. The workshop on Mechanic Automation and Control Engineering (MACE2010), in press.

DOI: 10.1109/mace.2010.5536886
