Development of Parrametric Modeling for the Spindle of NC Milling Machine Based on ANSYS

Abstract:

With the development of manufacturing technology, modern CNC machine tools are greatly improved in machine processing range, dynamic performance, the processing precision and reliability with the help of the modern design technology, process intensification and the new function part. The research object is mainly based on a CNC milling machine spindle system, using ANSYS software for the spindle of machine tool modeling, and then puting the design parameters into the already built parameterized model. It is known that the spindle is in high speed operation of the deformation and vibration characteristics by analyzing, the some unreasonable parameters were improved using some assumptions, so that the spindle is more stable and reliable in high speed and super high speed running dynamic performance, thus improving the processing precision fastly. Through the model analysis, this step is simplified in manufacturing prototype, thereby simplifying the cost, shorten the design cycle.

• Periodical: Applied Mechanics and Materials (Volumes 268-270)
• Pages: 926-930
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.268-270.926
• Online since: December 2012
• Authors: Ling Liu, Hui Bing Li
• Keywords: ANSYS Software, CNC milling machine, Parametric Modeling, Spindle

References

[1] HAO Qi, GUAN Liwen, WANG Jinsong, and WANG Living Dynamic Feedforward Control of a Novel 3-PSP 3-DOF Parallel Manipulator CHINESE JOURNAL OF MECHANICAL ENGINEERING Vol. 24,aNo. 4,a2011 676~683

DOI: 10.3901/cjme.2011.04.676

[2] GAO Feng, WANG Guofu, CUI Ying, and YANG Xinhong Dynamic Modeling and Analysis of 9-DOF Omnidirectional Legged Vehicle CHINESE JOURNAL OF MECHANICAL ENGINEERING Vol. 24,No. 4,2011 515~521

DOI: 10.3901/cjme.2011.04.515

[3] ZHOU Jie, WANG Shilong, KANG Ling, and CHEN Tianyi Design and Modeling on Stranded Wires Helical Springs CHINESE JOURNAL OF MECHANICAL ENGINEERING Vol. 24,No. 4, 2011 626~637

DOI: 10.3901/cjme.2011.04.626

[4] CUI Zhong Optimization Techniques and Applications on the High-Speed Grinder Design Hunan University for the degree of Doctor of Engineering November, (2010)

[5] MA yali The Energy Characteristic State Models for Mechanical System Conceptual Design,Dalian University of Technology for the degree of Doctor of Engineering, Septmber,(2011)

[6] Jin Quan Zhang, An Zhao, Jian Yong Song, Yun Yang Research on Parametric Modeling and Computing of Multi-Tower Suspension Bridge Based on ANSYS Applied Mechanics and Materials, May, 2012:178-181

DOI: 10.4028/www.scientific.net/amm.178-181.1983

[7] Z M Zhao,Modelling and simulation of a two-axis tracking system, Proceedings of the Institution of Mechanical Engineers, (2010)

[8] M Glavonjic, D Milutinovic, 3-axis parallel kinematic milling machine, The International Journal of Advanced Manufacturing Technology, (2010)

[9] Shu Kun Cao Milling Machine Design Based on Open CNC System, Applied Mechanics and Materials, (2011)

[10] Mingjin Chu, Xiangran Li, Jingzhou Lu, Xingmin Hou and Xiaogang Wang A Coupling Modeling Method with ANSYS/FLAC3D and its Application Applied Mechanics and Materials, May, 2012:170-173

[11] Na Jun Wang, Xiang Wang Jin, Jie Wang, Hai Long Diao Parameterized Finite Element Analysis System of Turbine Rotor Thermal Deformation Based on the Secondary Development of ANSYS Applied Mechanics and Materials, October, 2010:506-508。

DOI: 10.4028/www.scientific.net/amm.33.506
