Energy Storage Control Based on Wind Farm

Abstract:

With the increase in wind power generation and network capacity, Wind farm power fluctuations on the grid greatly. In order to improve the operational stability of wind farm grid, at its outlet to increase the energy storage system for the new environmentally friendly vanadium redox flow battery (VRB) to effectively regulate the grid power. According to the VRB equivalent mathematical model using a bidirectional DC/AC converter as VRB storage system power regulator, the corresponding charge discharge control and energy management strategy are designed , and grid-connected wind farm system with VRB energy storage unit are modeled and simulated. Simulation results show that the fluctuations in wind speed Circumstances, the VRB energy storage system can quickly and effectively smooth the fluctuations of the active power of the wind farm output, and can provide reactive support to the grid, effectively improve the operating performance of wind farm.

• Periodical: Applied Mechanics and Materials (Volumes 268-270)
• Pages: 933-936
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.268-270.933
• Online since: December 2012
• Authors: Xiao Dong Wang, Jin Hua Zhu, Ying Ming Liu, Hong Fang Xie
• Keywords: Energy Storage, Power Fluctuation, Vanadium Redox Flow Batter, Wind Farm

References

[1] BIALASIEWICZ J T, MULJADI E. The wind farm aggregation impact on power quality// Proceedings of the 32nd Annual Conference of IEEE Industry Electronic Society, November 7-10, 2006, Paris, France: 4195-4200

DOI: 10.1109/iecon.2006.347614

[2] LUO C, BANAKAR H, SHEN B, et al. Strategies to smooth wind power fluctuations of wind turbine generator. IEEE Trans on Energy Conversion, 2007, 22(2): 341-349.

DOI: 10.1109/tec.2007.895401

[3] LIAO Yong, HE Jinbo, YAO Jun, et al. Power smoothing control strategy of direct-driven permanent magnet synchronous generator for wind turbine with pitch angle control and torque dynamic control. Proceedings of the CSEE, 2009, 29 (18):71-77.

DOI: 10.5220/0009774503830390

[4] BAROTE L, WEISSBACH R, TEODORESCU R. Stand-alone wind system with vanadium redox battery energy storage// Proceedings of IEEE International Conference on Optimization of Electrical and Electronic Equipments, May 22-24, 2008, Brasov, Romania: 407-412

DOI: 10.1109/optim.2008.4602441

[5] ZHANG Buhan, ZENG Jie, MAO Chengxiong, et al. Improvement of power quality and stability of wind farms connected to power grid by battery energy storage system. Power System Technology, 2006, 30(15): 54-58.

DOI: 10.1109/icpst.2006.321662

[6] LI Xiao, HU Changsheng, LIU Changjin, et al. Modeling and controlling of SCES based wind farm power regulation system. Automation of Electric Power Systems, 2009, 33(9): 86-90.

[7] SHIBATA Akira, SATO Kanji. Development of vanadium redox flow battery for electricity storage. Power Engineering Journal, 1999, 13(3): 130-135.

DOI: 10.1049/pe:19990305
