Analysis of a Novel Isolated Input-Series and Output-Series Full-Bridge Bidirectional DC/DC Converter

Abstract:

A novel topology of isolated input-series and output-series (ISOS) full-bridge bidirectional DC/DC converter is described in this paper for the application requirement of high input voltage and high output voltage, which can be used in the next generation medium and high voltage power conversion systems. The proposed novel isolated bidirectional DC/DC converter not only can apparently decrease the stress of the switches, but also have the advantages, such as galvanic isolation, ease of realizing soft-switching control, high power density, and so on. In this paper, working principle of the proposed DC/DC converter is discussed in detail, the corresponding equations are derived, and the soft switching implementation is discussed too. In the end, simulation is done through PSIM to certify the feasibility of the proposed DC/DC converter and accuracy of the criterion.

You might also be interested in these eBooks

Manufacturing and Engineering Developments

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 273)

Pages:

399-403

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.273.399

Citation:

Cite this paper

Online since:

January 2013

Authors:

Xiao Yu Zhao, Cong Wang, Feng Yang, Su Ke Wang

Keywords:

Bidirectional DC/DC Converter, Input-Series, Isolated, Output-Series, Soft-Switching

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Jun Wang, Huang, A (2009) Smart grid technologies. In: Industrial Electronics Magazin, vol. 3, No. 2, p.16 – 23.

Google Scholar

[2] H. Tao, J. L. Duarte, M. A. M. Hendrix (2008) Three-port triple-half-bridge bidirectional converter with zero-voltage switching. In: IEEE Transactions on Power Electronics, Vol. 23, No. 2, Jan. pp.782-792.

DOI: 10.1109/tpel.2007.915023

Google Scholar

[3] Hua Bai, Chris. Mi (2008).

Google Scholar

[4] Xinbo Ruan, Wu Chen, Lulu Cheng, Tse, C.K., Hong Yan, Tao Zhang (2009) Control Strategy for Input-Series–Output-Parallel Converters. In: Industrial Electronics. Page(s): 1174 – 1185.

DOI: 10.1109/tie.2008.2007980

Google Scholar

[5] Qiwei Lu; Zijing Yang; Shuai Lin; Suke Wang; Cong Wang (2011) Research on Voltage Sharing for Input-Series-Output-Series Phase-Shift Full-Bridge Converters with Common-Duty-Ratio In: Annual Conference of IEEE Industrial Electronics, pp.1548-1553.

DOI: 10.1109/iecon.2011.6119537

Google Scholar

[6] Penghui Jing; Cong Wang (2012) Analysis of Isolated Three-level Half-bridge Bidirectional DC/DC Converter based on series resonant. In: International Symposium on Industrial Electronics, pp.194-199.

DOI: 10.1109/isie.2012.6237083

Google Scholar
