Cross Coupling Effect in Multi-Element Composites for Transducer Array Application

Abstract:

A novel three-phase (ceramic, epoxy resin and decoupling material) piezoelectric composite with multi-element in parallel connection has been developed by using dice-fill technology. This kind of composite consists of a large number of elements which can be seen as a single-sound radiation source. The space between elements is determined via a precise method of calculation. The ceramic elements are then cut using precision machinery to achieve exact results. A kind of decoupling material has been developed to decrease the cross coupling effect between elements. The vibration velocity curves of active elements and close elements were measured using a Scanning Laser Vibrometer (Polytec PSV-400). The results indicated that the decoupling materials induced in multi-element composites have a good decoupling effect. Vibration attenuations between adjacent elements are larger than 31 dB at resonance frequency.

• Periodical: Applied Mechanics and Materials (Volumes 275-277)
• Pages: 1650-1653
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.275-277.1650
• Online since: January 2013
• Authors: Lei Qin, Li Kun Wang, Yu Lu, Jing Jing Zhou
• Keywords: Actuator, Composite, Cross Coupling, Piezoelectric Properties, Vibration Attenuation

References

[1] D. M. Lu, Principles of Underwater Sound Transducer in Chinese (China Ocean University Press, Qingdao 2001).

[2] K. C. Cheng, H. L. W. Chan, IEEE Trans. UFFC. Vol. 50 (2003), pp.1177-1183.

[3] G. Li, L. K. Wang, G. D. Luan, in: World Congress on Ultrasonics. Ultrasonics International, Beijing, Vol. 44S (2005), p. e673-e677.

[4] A. A. Shaulov, W. A. Smith, R. Y. Ting, Ferroelectrics, Vol. 93 (1989), pp.177-182.

[5] L. Qin, L. Li, L. K. Wang, et al., J. Func. Mater. Vol. 38 (2007), pp.1824-1830.
