The Fault Tolerant Output Selector Based on Fault-Detection Considering Realistic Fault Modes for Pedal Simulator of Brake-by-Wire System

Abstract:

A brake pedal simulator in a Brake-by-Wire system is studied for fault tolerant control of the brake pedal signals. This study is conducted for the pedal simulator installed with a sensor that generates two analogue signals. Several realistic fault modes recognized by automotive experts have been analyzed. To solve the fault modes, we propose a fault tolerant output selector that can handle transient, intermittent, or permanent faults. The fault tolerant output selector, based on a fault detection algorithm, uses the BLS(brake light switch) signal and the Acc(acceleration pedal) signal to find faults and isolate them. To confirm the system performance, the fault modes were simulated. The result showed the reliability and safety of the pedal simulator for dealing with unexpected faults.

You might also be interested in these eBooks

Innovation for Applied Science and Technology

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 284-287)

Pages:

1946-1950

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.284-287.1946

Citation:

Cite this paper

Online since:

January 2013

Authors:

Jian Hu Li, Man Bok Park, Hun Mo Kim

Keywords:

Brake Light Switch (BLS), Fault Detection, Fault Tolerant, Fuzzy Exception Handler, Pedal Simulator

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Man Ho Kim, Suk Lee, Kyung Chang Lee, A fuzzy predictive redundancy system for fault-tolerance of x-by-wire systems, Elsevier, Vol.35, pp.453-461, (2011)

DOI: 10.1016/j.micpro.2011.04.003

Google Scholar

[2] Rolf Isermann, Editor, Fault-Diagnosis Systems An Introduction from Fault Detection to Fault Tolerance, Springer Publisher, Germany (2006)

Google Scholar

[3] R. Isermann, R. Schwarz, S. Stolzl, Fault-tolerant drive-by-wire systems, IEEE Control Systems Magazine, USA (2002), Vol.22, Issue5, p.64–81.

DOI: 10.1109/mcs.2002.1035218

Google Scholar

[4] Wongoo Lee, Young OK Lee, Minseok Jang, Choong Woo Lee, Chung Choo Chung, Han Byul Chung, Fault Tolerant Control of Sensor Fault of EPB System, Transactions of KSAE, Korea (2010)

DOI: 10.1109/cdc.2007.4434640

Google Scholar

[5] Jianhu Li, Qing Li, Manbok Park, Hunmo Kim, Permanent Sensor Fault-Tolerant Fuzzy Control for EMB Pedal Simulator, KSAE 2011 Anuual Conference and Exhibition, (2011) November23-26; Daejeon, Korea.

Google Scholar
