Design of Amplifying Circuit for Receiving Weak Signal for Laser Fuze

Abstract:

The echo signal received by laser fuze was very weak when the detection range increased. In order to expand the operating range of fuze, the reception capacity of fuze for weak signal should be improved. According to the requirements of long-range laser fuze receiving system as small volume, low-power, low-noise, high-gain, the amplifying circuit of the receiving system was analyzed and designed. To improve the ability of laser fuze for detecting weak signal, the high-sensitive, low-noise, inner-gain avalanche photodiode (APD) was used as a photodetector in the system, and the low-noise preamplifier and voltage amplifying circuit was designed. The noise and frequency response of the amplifying circuit was researched and analyzed by simulation and experiment. The results show that the design is effective and feasible, which can meet the requirements of processing circuit as receiving weak signal from long-distance.

• Periodical: Applied Mechanics and Materials (Volumes 300-301)
• Pages: 1012-1017
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.300-301.1012
• Online since: February 2013
• Authors: Bing Ting Zha, He Zhang, Jun Hong Wang, Jing Guo
• Keywords: Amplifying Circuit, APD, Laser Fuze, Weak Signal

References

[1] Chun Fang Fan, Feng Wang. Laser Fuze's Design of Emission Circuit[J]. Journal of Projectiles, Rockets, Missiles and Guidance, 2006, 26(2): 869-870.

[2] He Zhang. Detection and Recognition Technology[M]. Beijing: Beijing Institute of Technology Press, (2005).

[3] Fang Lin Deng, Yi Fei Zhang, Hui Yang. Research on Ranging Performance of Ballistic Missile's Laser Fuze[J]. Acta Simulata Systematica Sinica, 2005, 17(6): 1476-1479.

[4] Xiao Ling Lv. Study on the Receiver of Semiconductor Laser Range Finder[D]. Changchun: Changchun University of Science and Technology, (2006).

[5] Zheng Huang. Study on Pulse Laser Ranging Receiver Circuit [D]. Hangzhou: Zhejiang University, (2004).

[6] Xiang Jin Zhang. Research on the Design Theory & Application of Pulsed Laser Short Range Fixed Distance System[D]. Nanjing: Nanjing University of Science and Technology, (2007).

[7] Epitaxial Silicon Avalanche Photodiode Data Sheet[CD].

[8] Li Wang, He Zhang. Analysis and Design of Low Noise Information Receiving Circuits of a Laser Set Fuze[J]. Journal of Detection & Control, 2006, 28(3): 15-21.
