Determination of Stator Temperature Distribution for a Synchronous Machine

Abstract:

For studying the influence of the stator ventilation structure on the thermal performance of a synchronous machine, the mathematical model of the stator three-dimensional temperature fields is set up and the corresponding equations solved. The calculated results of the stator temperature are compared between different number of the radial ventilation ducts, which provides a theory foundation for the analysis and design of the cooling system and improves the safe operation condition of large synchronous machine.

• Periodical: Applied Mechanics and Materials (Volumes 300-301)
• Pages: 1018-1021
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.300-301.1018
• Online since: February 2013
• Authors: Bo Qiang Yuan, Xin Zhen Wu
• Keywords: Finite Element Method (FEM), Synchronous Machine, Temperature Field

References

[1] A. F. Heat: Flow in the stator core of large turbine generators by the method of three-dimensional finite elements. PartⅠ: analysis by scalar potential formulation; Part Ⅱ: temperature distribution in the stator iron. IEEE Trans. on PAS, Vol. 95, No. 5(1976).

DOI: 10.1109/t-pas.1976.32265

[2] M. S. Rajagopal, et al.: Finite element analysis of radial cooled rotating electrical machines. International Journal of Numerical Methods for Heat & Fluid Flow, Vol. 9, No. 1(1999), pp.18-38.

DOI: 10.1108/09615539910251086

[3] Yiping Lu: Fluid Flow and Temperature Field Simulation of Rotor of Large Turbo-generator with Air Coolant. Post-doctor Report, Harbin Science and Technology University(2007).

[4] J. P. Holman: Heat Transfer, McGraw-Hill Education(2011).

[5] Shunnian, Ding: Cooling of Large Motors, Beijing: Machinery Industry Press(1983).
