Effect of Bolt Hole Residual Stresses on Fatigue Performance of Truck Frame Rail Structures

Abstract:

The large numbers of bolt holes cut into truck frame side members act as joineries and points of attachments for various sub systems of the truck. While these bolt holes are unavoidable due to their primary functional importance, the near hole residual stress resulting from the type of hole cutting operation plays a significant role in deciding the fatigue performance of frame rail structures. If the residual stress is tensile in nature, this along with the surface roughness at the hole surface can lead to early initiation of fatigue cracks around bolt hole surface. In order to assess the extent of plastic deformation and resulting residual stresses in near hole areas of frame bolt holes cut using drilling, punching, laser cutting and water jet cutting processes, experimental investigation was carried out through microstructure analysis and X-ray diffraction measurements. Apart from this, an assessment of shot-peened hole surface was taken up to understand the effect of shot-peening on fatigue behavior of frame rail section with bolt holes. Also the test specimens extracted from frame rail sections were tested for comparing the fatigue life of specimens having bolt holes cut using different hole cutting operations.

• Periodical: Applied Mechanics and Materials (Volumes 300-301)
• Pages: 1089-1098
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.300-301.1089
• Online since: February 2013
• Authors: K. Chinnaraj, Prasad M. Sathya, Rao C. Lakshmana
• Keywords: Bolt Hole, Fatigue Behavior, Microhardness, Plastic Deformation, Residual Stress, Truck Frame, X-Ray Diffraction (XRD)

References

[1] J. Liu, Z.F. Yue, et al: Surface Finish on open holes on fatigue life, Theoretical and Applied Fracture Mechanics 47 (2007) 35-45.

DOI: 10.1016/j.tafmec.2006.10.008

[2] J. Liu, H.L. Xu, et al: Effect of detail design on fatigue performance of fastener hole, Materials and Design 31 (2010) 976-980.

DOI: 10.1016/j.matdes.2009.08.016

[3] GU Weiping, XU Honglu, et al: Effect of Drilling Process on Fatigue Life of Open Holes, Tsinghua Science and Technology ISSNl1007-0214 11/21 Vol 14 (2009) 54-57.

DOI: 10.1016/s1007-0214(10)70031-6

[4] J. Liu, J.X. Kang, et al: Prediction of fatigue performance of fastener holes with bolt clamping force based on critical plane approach, Material Science and Engineering A 527 (2010).

DOI: 10.1016/j.msea.2010.02.028

[5] M. Bernard, T. Bui-Quoc, M. Burlet: Effect of re-cold working on fatigue life enhancement of a fastener hole, Fatigue and Fracture of Engineering Materials and Structures 8 (1995) 765-775.

DOI: 10.1111/j.1460-2695.1995.tb00902.x

[6] Poussard C, Pavier M.J., Smith D.J.: Analytical and finite element predictions of residual stresses in cold worked fastener holes, Journal of Strain Analysis 30 (1995) 291-304.

DOI: 10.1243/03093247v304291

[7] M. Priest et al: An assessment of residual stress measurements around cold-worked holes, Experimental Mechanics (1995) 361-366.

DOI: 10.1007/bf02317546

[8] M.J. Pavier, C.G.C. Poussard, D.J. Smith: A finite element simulation of the cold working process for fastener holes, Journal of Strain Analysis for Engineering Design 32 (1997) 287-300.

DOI: 10.1243/0309324971513418

[9] M.J. Pavier, C.G.C. Poussard, D.J. Smith: Effect of residual stress around cold worked holes on fracture under superimposed mechanical load, Engineering Fracture Mechanics 63 (1999).

DOI: 10.1016/s0013-7944(99)00050-8
