Size Effect on Pull-In Behaviors of Electrostatically Actuated Cantilever Micro-Beams

Abstract:

For the deformation problem of an electrostatically actuated cantilever micro-beam, size effect on pull-in behaviors of the micro-beams have been studied based on modified couple stress theory. The approximate analytical solutions to the pull-in voltage and pull-in displacement of the micro-beam are derived by using the Rayleigh-Ritz method. The results show that the normalized pull-in voltage of the cantilever micro-beam is size-dependent and the normalized pull-in displacement of the micro-beam is size independence.

• Periodical: Applied Mechanics and Materials (Volumes 300-301)
• Pages: 889-892
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.300-301.889
• Online since: February 2013
• Authors: Sheng Li Kong
• Keywords: Couple Stress, Pull-In, Size Effect, Trial Function

References

[1] H. Nathanson, W. Newell, R. Wickstrom et al. ：IEEE T. Electron. Dev. (1967), P. 117.

[2] A. Nayfeh, M. Younis, E. Abdel-Rahman: Nonlinear Dyn. (2005), P. 211.

[3] F. Yang, A. Chong, D. Lam et al.: Int. J. Solids Struct. (2002) ,P. 2731.

[4] S. Senturia: Microsystem design (KAP, London 2001).

[5] Y. Hu, P. Chang, W. Chuang et al.: J Micromech Microeng (2007),P. 1870.

[6] H. Tilmans, R. Legtenberg: Sensor Actuat. A-Phys. (1994), P. 67.
