Design and Verification for Data Interface 8051_USB IP Core

Abstract:

A series of portable mass storage devices are arising due to the effective support from USB interface for its special features, such as easy to use, a high transfer speed and low price. 8051_USB IP core is to achieve data acquisition and efficient data transfer to PC. The abstract of USB Protocol is introduced firstly. Then the design and verification of 8051_USB IP core are discussed in detail. Modules of 8051_USB protocol controller are designed with Verilog HDL. The design is simulated with Modelsim.

• Periodical: Applied Mechanics and Materials (Volumes 321-324)
• Pages: 387-390
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.321-324.387
• Online since: June 2013
• Authors: Ya Li Chen, Li Kun Zheng, Zhe Ying Li
• Keywords: 8051, Ip Core, USB, Verilog HDL

References

[1] Zhiyong Zhang, Tiejun Lu, Xiaobin Chu. Design And Implementation Of Embedded Data Acquisition System Based On USB And Flash Multimediacard Memory. Second International Conference on the Digital Society, IEEE, 2008:31-34.

DOI: 10.1109/icds.2008.19

[2] Bi Bo, Sun Shuying, Wang Chunping. Design of Data Acquisition Equipment Based on USB, The Eighth International Conference on Electronic Measurement and Instruments, IEEE, 2007:866-869.

DOI: 10.1109/icemi.2007.4350590

[3] Thiago P Mussolini, Leonardo B Zoccal, Tales C Pimenta. Integration of IPs into the M8051 Microcontroller, IEEE, 2012.

DOI: 10.1109/spl.2012.6211769

[4] HongZhang. The Design of USB Interface, Xi'an:Xi'an Electronic and Science University Press, 2002.

[5] GeShen. The Research of SOC Design Methodology Based on Reusable IP Cores. Xi'an: Northwestern Polytechnical University, 2002.
