Numerical Simulation on the Shape of Stamping Part about Hot Forming and Quenching

Abstract:

With the application of ultra high strength steel in vehicle manufacturing field, the hot forming method which is used to form the high strength sheet at high temperature and cool rapidly in dies to obtain the final part has been studied extensively. In this paper, The FE model that contained thermal mechanical-microstructure and strain model represented by a mixture law for hot forming was discussed, and further been applied to hot forming and quenching process simulation of 22MnB5 metal sheet of U-shape constant section part. The computed results of final part shape and hardness after cooled in air, in water without dies and cooled within dies were compared respectively.

• Periodical: Applied Mechanics and Materials (Volume 328)
• Pages: 450-456
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.328.450
• Online since: June 2013
• Authors: Wei Wang, Yu Liu, Peng Fei Wen, Jun Tong
• Keywords: Hot Forming, Mixture Law, Quenching, Thermo-Mechanical-Transformation Coupled Analysis

References

[1] H. Karbasian. A Review on Hot Stamping. Journal of Materials Processing Technology, 2010, (210): 2103-2118.

DOI: 10.1016/j.jmatprotec.2010.07.019

[2] A.J. DeArdo, J.M. Gray and L. Meyer. Niobium 81 (San Francisco), Ed. H. Stuart, (Warrendale, PA: TMS-AIME, 1984), 685-701.

[3] Gracious Ngaile. Simulations of Manufacturing Processes: Past, Present and Future. Proceedings of the 7th ICTP, Yokohama, Japan, Oct 27-Nov 1, 2002, 271-282.

[4] Paul Akerstrom, Modelling and Simulation of Hot Stamping, SE-97187 Lulea Sweden (2006).

[5] Ambikapathy Naganathan. Hot Stamping of Manganese Boron Steel. Ohio state, The Graduate School of The Ohio State University, 2010. 38-57.

[6] B. Shapiro. Using Ls_Dyna for Hot Stamping. 7th European LS-DYNA Conference.

[7] B. Hochholdinger,H. Grass. Determination of Flow Curves by Stack Compression Tests and Inverse Analysis for the Simulation of Hot Forming. 7th European LS-DYNA Conference.

[8] H.G. Kim, H.S. Son, S.H. Park, Development of Thermal-Mechanical Coupled Simulation Skills for Hot Press Forming Tool Design. POSCO TECHNICAL REPORT, 2006, VOL. 10 No. 1: 115-123.

[9] P Akerstrom, M Oldenburg , Austenite Decomposition during Press Hardening of A Boron Steel -Computer Simulation and Test. Journal of Materials Processing Technology , 174 (2006): 399-406.

DOI: 10.1016/j.jmatprotec.2006.02.013

[10] Tobias Olsson, An Ls-DYNA Material Model for Simulations of Hot Stamping Processes of Ultra High Strength Steels 7th European LS-DYNA Conference.

[11] LS-DYNA_manual_R6. 0. 0.

[12] Theodore L. Bergman, Fundamentals of Heat and Mass Transfer, John Wiley & SonsLtd, Missouri. 2011. 468-564.
