Study on Dynamical-Filtering Roller-Type Oil Screen Pipe Based on Ordinary Gear Train

Abstract:

In this paper, a new structure of dynamical-filtering roller-type screen pipe based on ordinary gear train is put forward. In light of the working conditions of the oil pump, the operating principle of this kind of screen pipe is presented. Three-dimensional model and computational fluid dynamical (CFD) model for flow filed analysis are established. Then, pressure exerted on the blades of the impeller wheel in the screen pipe is calculated in FLUENT, which yields the torque on the impeller shaft and explains the mechanism of dynamical filtering. Transmission device is finally designed on the basis of the maximal torque on the impeller shaft.

• Periodical: Applied Mechanics and Materials (Volume 33)
• Pages: 623-626
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.33.623
• Online since: October 2010
• Authors: Shao Jie Xin, Ii Zhong
• Keywords: Dynamical Filtering, Flow Field Analysis, Ordinary Gear Train, Power Source, Roller-Type Screen Pipe

References

[1] D.H. Liu, X.Y. Song, Y.H. Liu, et. Al: Petroleum Machinery Vol. 32 (2004), pp.13-16.

[2] S.J. Xin, X.T. Su: Petroleum Machinery Vol. 35 (2007) No. 1, pp.19-21.

[3] Younsi Mohand, F Bakir, S Kouidri and R Rey: Journal of Power and Energy Vol. 221 (2007) No. 7, pp.1025-40 Torque [kN·mm] Angle [degree].
