Complete Equipment Inspection Method Based on Risk Assessment and Nondestructive Testing

Abstract:

Three propylene spherical tanks which have both the same manufacturing parameters and conditions have been assessed based on risk assessment and non-destructive testing technology. One of the spherical tanks is stopped for comprehensive inspection, and the result of inspection verifies the reliability of risk assessment, which is applied to other two unopened propylene spherical tanks. Meanwhile, in order to make overall inspection level meet the requirements of the risk assessment and so reduce spherical tanks assessing risk, ultrasonic diffraction detection (TOFD) with high detection rate and fluorescent magnetic surface detection technology are adopted to ensure comprehensive test meeting the risk assessment requirements, which can also provide significant guidance for future complete equipment inspection.

• Periodical: Applied Mechanics and Materials (Volume 330)
• Pages: 242-249
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.330.242
• Online since: June 2013
• Authors: Hui Huang, Ding Yue Chen, Guo Jun Mao, Hui Chen
• Keywords: Complete Equipment, Fluorescent Magnetic Test, Inspection, Risk-Based Inspection (RBI), Ultrasonic Diffraction Detection (TOFD)

References

[1] China Association of Special Equipment Inspection, Hefei General Machinery Research Institute, Inspection knowledge of large complete sets of petrochemical, 2011.

[2] General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, TSG R0004-2009 Stationary Pressure Vessels Safety Technology Supervision, China Standardization Press, 2009.

[3] Xuedong Chen and Bing Wang, "Practice of RBI in Chinese Petrochemical Enterprises and Discussion about Its Several Questions," Pressure Vessel Technology, vol. 21, 2004, pp.39-45.

[4] Weidhe Guan, Zhibing Ai and Changzhou Yan, "Nondestructive Testing of Pressure Equipment on RBI," Pressure Vessel Technology, vol. 27, 2010, p.47–50.

[5] Junwei Shi and Songping Liu, "Ultrasonic TOFD Technology for Detection," Aeronautical Manufacturing Techonology, vol. S1, 2009, p.96–100.

[6] Liang Fan, "Application of Tofd Detection Technology to Periodical Inspection of Pressure Vessels," Nondestructive Testing, vol. 31, 2009, p.914–916.

[7] Xiaomin Liu, Youde Zhang and Dongxu Pang, "Use of Fluorescent Magnetic Particle Testing for the Inspection of Surface Defects on Important Pressure Vessels," Pressure Vessel Technology, vol. 21, p.49–5.
