A Novel Method to Measure Flange Thickness and Rim Width of Wheel Sets on Line

Abstract:

The flange thickness and rim width of the wheel sets are key parameters which ensure the train security. This paper proposes a novel real-time method to measure flange thickness and rim width of wheel sets based on laser displacement sensors. Three laser displacement sensors are cramped on the steel rails. The light of sensors travels through the slit between rails, reaching a point which is 12mm below the wheel set tread. The flange thickness and rim width can be measured by three laser displacement sensors together. This non-contact method realize dynamic and real-time measurement of the wheel sets parameters. The measurement error is 0.2mm, which meet rail industry standards.

You might also be interested in these eBooks

Materials Engineering and Automatic Control II

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 330)

Pages:

237-241

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.330.237

Citation:

Cite this paper

Online since:

June 2013

Authors:

Jian Chun Ji, Shuang Yun Shao, Qi Bo Feng

Keywords:

Dynamic Measurement, Flange Thickness, Laser Sensor, Rim Width

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] SUN Shanchao, WANG Chengguo, LI Haitao, et al. Analysis of Wheel/Rail Contact Geometric Parameters' Effect on the Dynamic Behavior of High-Speed Passenger Car [J] . China Railway Science, 2006, 27 (5): 93- 98. in Chinese.

Google Scholar

[2] Joes Luis Lopez Gomez. Installation for measuring the wheel offset of railway vehicles [P].US6003232.

Google Scholar

[3] Danneskiold-Samsoe. Apparatus for track-based detection of the wheel profile of passing railway wheels [P].US4932784.

Google Scholar

[4] Mian. Contactless wheel measurement system and method[P]. US006768551B2.

Google Scholar

[5] FENG Qibo, CHEN Shiqian. A new method for automatically measuring geometric parameters of wheel-sets by laser, 5th International Symposium on Instrumentation and Control Technology, Vol.5253 (2003) pp.110-113.

DOI: 10.1117/12.521460

Google Scholar
