Study on the Control System of Electric Vehicle Anti-Rollover Based on DSP

Abstract:

According to the actual need of vehicle anti-rollover, based on the current technology of measuring speed, weighing and measuring turn angle, an anti-rollover control system with differential braking and turn angle limit function for electrical vehicle was researched. The system uses data signal processor (DSP) as the core controller, and includes the speed measuring circuit, the weighing circuit, the steering angle measuring circuit and the steering wheel control circuit. The speed measuring circuit using the orthogonal pulse photoelectric encoder and DSP can realize the acquisition and calculation of speed. The weighing circuit with capacitance sensor can convert the load of vehicle axle to the voltage signal. A/D conversion is completed by DSP, and the vehicle load is calculated with V-M mathematic model. The turn angle measuring circuit is composed of the photoelectric angle sensor, the filter and DSP' counter. The control program of the system was also designed.

• Periodical: Applied Mechanics and Materials (Volumes 336-338)
• Pages: 779-783
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.336-338.779
• Online since: July 2013
• Authors: Xin Min Xiong, Yan Hou
• Keywords: Anti-Rollover, Control System, Digital Signal Processor (DSP), Electric Vehicle (EV), Measuring Angle, Measuring Speed, Weighing

References

[1] S.Gosselin-Brisson, M.Bouazara, and M.J. Richard: Design of an active anti-roll bar for off-road vehicles, J. Shock & Vibration, 2009, vol.16, issue 2, pp.155-174.

DOI: 10.1155/2009/343048

[2] P.H. Cronjé, and P.S. Els: Improving off-road vehicle handling using an active anti-roll bar, J. Journal of Terramechanics, 2010, vol. 47, issue 3, pp.179-189.

DOI: 10.1016/j.jterra.2009.09.003

[3] Ming Wan, Houlin Li, and Hua Tian: A Research of Maximum Roll Stability Angle Measures of Automobile, J. Drive System Technique, 1999, issue 4, pp.37-41, in Chinese.

[4] Changfu Zong, and Konghui Guo: Study and Evaluation on the Controllability and Stability of Automobiles, J. Automobile Technology, 2000, issue 6, pp.6-11, in Chinese.

[5] Feng He, Liyong Yang, and Zhangyi Liu: Study on Differential-Braking-Based Vehicle Dynamics Control with Rollover Prevention, J. Modern Machinery, 2003, issue 5, pp.31-33, in Chinese.

[6] Shushan Xu, Junxia Guo, and Sanxu Yang: Electron Influence on Characteristics in Capacitance Weighing Sensor of Traffic with Velocity and Acceleration, J. Journal of Henan Normal University (Natural Science), 2008, vol.36, issue 5, pp.65-68, in Chinese.

[7] Baoyu Wang, Dongmin Wang, and San-xu Yang: A Research on V-M Nonlinear Compensation of Vehicle Weighing with Capacitance Transducer, J. Henan Science, 2007, vol.25, issue 2, pp.263-265, in Chinese.
