Analysis of Hopf Bifurcation of Steering Wheel Shimmy of Automobile

Abstract:

It proves that steering wheel shimmy is a vibration of stable limit cycle occurring after Hopf bifurcation, which is elaborated by nonlinear dynamics theory, and the control objectives of shimmy are proposed according to its bifurcation properties. Numerical analysis of bifurcation characteristics has been conducted with a nonlinear shimmy model whose parameters come from a domestic automobile with independent suspension. The results indicate that when the speed reaches 49.98Km/h, supercritical Hopf bifurcation occurs to the system and stable limit cycle appears, i.e. wheels oscillate around the kingpin at the same amplitude; when the speed comes to 76.30 Km/h, Hopf bifurcation occurs again and limit cycle disappears. The bifurcation speed and amplitude of limit cycle match the shimmy speed and amplitude measured from road experiments very well, which confirms the conclusions that shimmy is a vibration of stable limit cycle occurring after Hopf bifurcation at critical speed.

You might also be interested in these eBooks

Advanced Research on Applied Mechanics, Mechatronics and Intelligent System

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 344)

Pages:

61-65

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.344.61

Citation:

Cite this paper

Online since:

July 2013

Authors:

Li Juan He, Yu Cun Zhou

Keywords:

Hopf Bifurcation, Limit Cycle, Steering Wheel Shimmy

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] LIN Yi, HE Li-juan. Overview of Automobile Front Wheel Shimmy in Nonlinear Field. Transactions of the Chinese Society for Agricultural Machinery, 38 (2007) 174-177.

Google Scholar

[2] SHU Zhong-zhou, ZHANG Ji-ye, CAO Deng Qing. The Stability of Motions. China Railway Publishing House, Beijing, (2001).

Google Scholar

[3] Hamzi B, Kang W, Barbot J. Analysis and Control of Hopf Bifurcations. SIAM J. Control Optimization Math, 42(2004)2200-2220.

DOI: 10.1137/s0363012900372714

Google Scholar

[4] LI Sheng. Study on Mechanism and Control Strategies of Vehicle Steering Wheel Shimmy with Bifurcation Theories, Jilin University, Changchun, (2005).

Google Scholar

[5] Dave Crolla, YU Fan. Vehicle Dynamics and Control. China Communication Press, Beijing, (2004).

Google Scholar

[6] ZHANG Ji-ye, YANG Yi-ren, ZENG Jing. An Algorithm Criterion for Hopf Bifurcation and Its Applications in Vehicle Dynamics. Chinese Journal of Theoretical and Applied Mechanics, 32(2000)596-605.

Google Scholar
