Development and Application of Portable Mining Vibration Recorder

Abstract:

t has been a bottleneck for the application of vibration-related techniques in the coal mine that the vibration data cannot be acquired due to lack of mining vibration instrument. This paper discussed the development of a portable mining vibration recorder, introduced its overall scheme, as well as its hardware and software design in detail. The developed recorder is a coal mine intrinsically safety instrument based on ARM system, with features of 4 channels analog input, 2GB large volume storage memory, 250kHz sampling frequency, no less than 3.5h full-payload continuous working time with battery supply, fitted to record and deposit the vibration signal of the equipment in atmospheres with methane and coal dust explosive mixture. The authors carried out a series of testing application in ChengZhuang coal mine. The experimental results show that the data acquired by the recorder is true and valid. Study provides an instrumental basis of apparatus to carry out the supervision of machine based on vibration detection in coal mine.

• Periodical: Applied Mechanics and Materials (Volume 345)
• Pages: 108-111
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.345.108
• Online since: August 2013
• Authors: Guang Hui Xue, Jun Zhang, Xiao Dong Ji, Xin Ying Zhao
• Keywords: ARM, Condition Monitoring, Fault Diagnosis, Recorder, Underground Coal Mine, Vibration Measurement

References

[1] LI Xiang-chun, NIE Bai-sheng, HE Xue-qiu. Mechanism of coal and gas bursts caused by vibration [J]. JOURNAL OF UNIVERSITY OF SCIENCE AND TECHNOLOGY BEIJING, 2011, Vol. 33(2) ：149-152.

[2] ZHANG Li-rong. Analysis of Vibration of Gear Box of Hoist [J]. Coal Mine Machinery, 2011, 32(10): 274-276.

[3] JIA Hong-gang, LI Zhen, CAO Hong. Application of Vibration Monitoring Analyzer in Fault Diagnosis of Coal Mine Electromechanical Equipments [J]. Industry and Mine Automation, 2011, 37(8): 11-13.

[4] LI Chuan-tao, HAO Wei, HAO Wang-shen, et al. Study on Coal Gear Box Status Predictive Method Based on Band Vibration Severity and ARIMA [J]. COAL MINE MACHINERY, 2011, 32(4): 251-253.

[5] XUE Guanghui, ZHAO Guorui, ZHU Shigang, et al. Express detection method on the crack flaw of large vibrating screen lower beam based on MMMT and ET [J], Journal of china coal society, 2010 Vol. 35 (7) : 1215-1218.

DOI: 10.1109/mesa.2010.5552045

[6] YAN Zhixin, PENG Ningbo, JIANG Ping, et al.. Research about blasting vibration safety criteria [J]. Journal of china coal society, 2011 Vol. 36 (8): 1281-1284.

[7] XUE Guang-hui, WU Miao, ZHOU Bin. Development of mine portable digital recorder [J]. COAL SCIENCE AND TECHNOLOGY, 2004, 32(5): 52-54.

[8] ZHOU Li-zhi, ZHOU Peng-chong, XUE Guang-hui, et al. Study on multi-channel data collection system in underground mine [J]. COAL ENGINEERING, 2006, 19(1): 71-72.
