Space Rigid Frame Damage Identification Method Based on Modal Analysis

Abstract:

Space frame structure of no damage and injury finite element models were established with ANSYS, and analyze 3D curvature mode as well three-dimensional vibration mode variety rate of the space rigid frame based on modal analysis. Curvature mode and three-dimensional vibration mode variety rate as the labeled amount was selected and applied to structural damage. The calculated results showed that the first-order curvature mode not only identify against single or multiple damage location, but also determine the initial degree of injury, and the axial curvature mode is better than the horizontal curvature mode for damage identification; The calculated results also showed that the variety rate of the first-order vibration mode can identify against damage location. Methods were provided by identifying the space frame structural damage of the curvature mode or three-dimensional vibration mode variety rate.

• Periodical: Applied Mechanics and Materials (Volumes 351-352)
• Pages: 1244-1248
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.351-352.1244
• Online since: August 2013
• Authors: Hong Yu Jia, Peng Fei Yue, Xiao Fei Wang
• Keywords: Damage Identification, Modal Analysis, Space Rigid Frame, Structural Damage

References

[1] Hongping Zhu, Jing Yu, Junbing Zhang. A Summary Review and Advances of Vibration-Based Damage identification Methods in Structural Health Monitoring [J], Engineering Mechanics 2008. 02. 2828(2): 1-17(In Chinese).

[2] Xiaodan Sun, Jinping Ou. Assessment of vibration-based damage indexes in structural health monitoring [J] Journal of Vibration and Shock 2009, (1): 9-14(In Chinese).

[3] Peiying Gu, Houqun Chen, Tongchun Li. Based on the damage strain mode for the structural damage identification directly index method[J], Progress in Natural Science 2007, (2): 240-247(In Chinese).

[4] Gang Xue, Meifeng Cai. Study on Damage Detection of Reinforced Concrete Beam Based on Curvature Mode [J], Construction Technology 2008. 12(37): 325-328(In Chinese).

[5] Ling Zhao, Aiqun Li. Structural damage identification method based on elemental strain energy change ratio [J], Journal of Southeast University 2007. 1137 (6): 1052-1056(In Chinese).

[6] Wangji Yan, Tianli Huang, Weixin REN. Statistical damage identification of structures based on element modal strain energy sensitivity Journal of Central South University 2011. 0142(1): 152-157 (In Chinese).

[7] Yongmei Li, Xiyuan Zhou, Xiangyu Gao, Lin Geng, Xuying Zhao. Damage Diagnosis of Beam Structures by Flexibility Curvature Method Journal of Beijing University of Technology 2008, 34(11): 1173-1178(In Chinese).

[8] Kaiyin Zhang, Zhihua Sun, Xiaojun Zou, Guangqiao Xue, Bingbing Zhang. Curvature Mode Technique of Damage Identification for Beam Bridge Structure Journal of Wuhan University of Technology 2004, 28(6): 855-858(In Chinese).

[9] Hongxia Duan, Shouju Li, Yingxi Liu, Xudong Yuan. Two-stage damage diagnosis approach for steel frame structures Journal of Dalian University of Technology 2011, 51(1): 7-13(In Chinese).
