Innovation Design of the Multi-Operational CNC Lathe Based on TRIZ Theory

Abstract:

Theory of Inventive Problem Solving is introduced in this paper, including its fundamental principles and methods. Contradiction matrix and substance-field analysis are used to solve the concept design problems in engineering. Based on this method, the processing problems of a wrench element are worked out, and 3d model of the multi-operational CNC lathe is designed through SolidWorks software, then the dynamic performance of mechanical subsystem and the strength of key parts are simulated and analyzed, and the results show that the machine tool proves to be successful to meet the intended high precision of the work-piece.

• Periodical: Applied Mechanics and Materials (Volume 364)
• Pages: 129-133
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.364.129
• Online since: August 2013
• Authors: Yan Jin, Shao Jun Liu
• Keywords: CNC Lathe, Creative Design, Inventive Principle, Multi-Operational, TRIZ

References

[1] Tan Runhua: Innovative design-TRIZ: Theory of Invention Problem Solving (China Machine Press, Beijing 2002).

[2] Niu Zhanwen and Xu Yan: submitted to Journal of China Mechanical Engineering (1999).

[3] Zhang Weiguo, Zhang Guoquan, He Hai and Zhong Yifang: submitted to Journal of Machine Design and Research (2005).

[4] Mu Yongcheng and Qu Shiyong: submitted to Journal of Modular Machine Tool and Automatic Manufacturing Technique (2008).

[5] Li Min, Zhang Mingqin, Zhang Ruijun and Su qian: submitted to Journal of Hoisting and Conveying Machinery (2010).

[6] Wang Keyin: SolidWorks 2011 Chinese Standard Case Tutorials (China Machine Press, Beijing 2002).
