Analysis of Influence Factors on Springback for Blade of Stamping Welded Hydrodynamic Torque Converter

Abstract:

In order to reduce the effect of springback on the performance of stamping welded hydrodynamic torque converter in the blade manufacturing process, we carried on the numerical computation of stamping forming and springback on the pump blade of torque converter , which is based on the sheet metal forming finite element theory. Analysis of the influence factors on springback for the pump blade of torque converter includes the different die speed, die clearance, friction coefficient and sheet thickness, by which we obtained main rule effect springback of torque converter blades. This work provides an reliable basis for blades springback compensation design which can improve the forming accuracy of torque converter blades.

• Periodical: Applied Mechanics and Materials (Volumes 365-366)
• Pages: 1203-1206
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.365-366.1203
• Online since: August 2013
• Authors: Yue Tan, Wen Xing Ma, Tian Ming Yu
• Keywords: Influence Factor, Numerical Calculation, Pump Blade of Torque Converter, Springback

References

[1] Hui Xie: Journal of Hunan University(Natural Sciences) Vol. 30(5)(2003), pp.29-34, in Chinese.

[2] Lei Chen, Jichang Yang, Liwen Zhang: Materials Science & Technology Vol. 15(2)(2007), pp.269-272, in Chinese.

[3] M.H. Parsa, S. Nasher al ahkami, H. Pishbin, et al: Materials and Design Vol. 41(2012), pp.326-337.

DOI: 10.1016/j.matdes.2012.05.009

[4] Y.E. Ling, H.P. Lee, B.T. Cheok: Journal of Materials Processing Technology Vol. 168(2005), pp.296-302.

[5] M. Firat: Materials and Design Vol. 28(2007), pp.147-154.

[6] Bingkun Xu, Fazhong Shi: Journal of Beijing University of Aeronautics and Astronautics Vol. 27(2)(2001), pp.194-197, in Chinese.

[7] Maotao Zhu, Yongjian Zhang, Lili Zhang: Transactions of the Chinese Society for Agricultural Machinery Vol. 39(6)(2008), pp.189-192, in Chinese.
