The Monitoring of Machine Tool Working State Based on Load Current Signal

Abstract:

According to the characteristic of machine tools such as complex driving chain and enclosed housing, this paper selects current signal which is easy to sample as the analytical signal. As the machines tools use different driving chain in different work state, this will affect motor current of machine tools; that is, the characteristics under different working conditions will be included in the current signal. This paper chose wavelet packet decomposition to analyze the current signal, then extracted wavelet packet coefficients of different frequency bands, by the change of wavelet packet coefficient to determine the machine's working condition. From the analysis of lathe current signal sampled in the experiment, it indicates the validity of wavelet packet coefficients as a feature quantity of the machine condition monitoring.

• Periodical: Applied Mechanics and Materials (Volumes 37-38)
• Pages: 1512-1515
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.37-38.1512
• Online since: November 2010
• Authors: Guang Lin Yu, Guo Fu Li
• Keywords: Condition Monitoring, Current Signal, Frequency Distribution, Wavelet Packet Coefficients

References

[1] K.N. Zhang and Y.J. Chen: Machine Tool and Hydraulics, Vol. 35 (2007) No. 3, pp.196-198. (In Chinese).

[2] Y.B. Song, R.M. Fang and X.F. Lu: Electric Motor and Control Application, Vol. 3 (2009) No. 36, pp.38-42. (In Chinese).

[3] L.H. Gao, W. Yang and C.S. Zhou: Journal of Lanzhou University of Technology, Vol. 33 (2007) No. 1, pp.59-61. (In Chinese).

[4] M.L. Liu, X.D. Hu and S.M. Cui: Journal of Harbin Institute of Technology, Vol. 37 (2005) No. 6, pp.836-838. (In Chinese).

[5] C.H. Hu, G. H. Li and T. Zhou: System Analysis and Design Based on MATLAB 7. X (Xi'an University of Electronic Science and Technology Press, China 2008).

[6] X.D. Ni: Mechanism Manufacture Technology Basis (Tsinghua University Press, China 2007).
