PLC Applied in the Three-Phase Stepper-Motor Control System

Abstract:

The paper gives the introduction of characteristics and the work principle of the three-phase stepper motor. A method based on Siemens PLC (programmable logic controller) to the three-phase stepper motor control, PLC controlled the stepper motor by changing the system control parameters corresponding program to realize the three-phase stepper motor start and stop control, positive/negative control and speed control, can improve the control system flexibility and reliability, and obtain good control and accurate position.

• Periodical: Applied Mechanics and Materials (Volumes 385-386)
• Pages: 791-794
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.385-386.791
• Online since: August 2013
• Authors: Xiao Yu Bu, Ping Liu
• Keywords: Control System, Programmable Logic Controller (PLC), Three-Phase Stepper Motor

References

[1] Wang Yonghua. The Modern Electrical Control and PLC Application Technology [M]. Beijing: Beijing University of Aeronautics and Astronautics Press, (2005).

[2] Tan Jiancheng. New Motor Control and Application-specific Integrated Circuits and Application [M]. Mechanical Technology Press, 2006: 48-56.

[3] Jung-Chien li. A Phase/Frequency-Locked Controller for Stepping Servo Control System. IEEE Transactions on Industry Electronics. 1986. 39(2): 112-119.

DOI: 10.1109/41.166732

[4] Wang Tingyou. The Principle and Application of Programmable Controller [M]. Beijing: National Defense Industry Press. (2008).

[5] Li Wenhui, Li Guoqiang. Stepping Motor Control System Design Based on PLC [J]. Instrument Technology. (2008).

[6] Hu Xuelin, Song Hong. Electrical Control and PLC [M]. Beijing: Metallurgical industry press. (1997).
