Stack Cooling Profile of an Air-Cooled 3-Cell Polymer Electrolyte Membrane Fuel Cell Stack

Abstract:

A locally designed, 3-cell closed cathode PEM fuel cell stack was developed as a platform for thermal engineering studies. Stack polarization behavior is combined with thermal behavior analysis to identify the cooling profiles of an air-cooled fuel cell stack under variable load and cooling settings. The objective of the study is to identify the bulk thermal effects of the stack under cooling for further consideration in fuel cell system control development. The stack is designed with 40 cooling channels and tests were conducted with airflows in the range between 200 and 400 Reynolds number. Different fan settings are applied to analyze the response of the design to negative and positive pressure airflows. The temperature measurements are translated into an averaged stack temperature and a subsequent second order thermal analysis showed that an exponential cooling trend is obtained. Analytical evaluation on the dynamic cooling rates relative to response time and cooling trend is also performed and reported.

• Periodical: Applied Mechanics and Materials (Volume 393)
• Pages: 774-780
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.393.774
• Online since: September 2013
• Authors: Wan Ahmad Najmi Wan Mohamed, R. Atan
• Keywords: Air Cooling, Cooling Profile, Negative Pressure, PEM Fuel Cells, Positive Pressure

References

[1] W. A. N. W. Mohamed, R. Atan. Optimizing air cooling capability of PEMFC through case-by-case cooling channel analysis. Proc. Int. Conf. on Advances in Mech. Eng. (ICAME) (2009) Malaysia.

[2] S-Wu Perng, H-Wen Wu. Heat transfer in a PEMFC flow channel. Ap. Therm. Eng. 29 (2009) 3579-3594.

DOI: 10.1016/j.applthermaleng.2009.06.012

[3] G. Zhang, Satish. G. Kandlikar. A critical review of cooling techniques in proton exchange membrane fuel cell stacks Int. J. Hydrogen Energy 37 (3) (2012) 2412-2429.

DOI: 10.1016/j.ijhydene.2011.11.010

[4] M. Matian, A. Marquis, N. Brandon. Model based design and test of cooling plates for an air-cooled polymer electrolyte fuel cell stack, Int. J. Hydrogen Energy 36 (2011) 6051-6066.

DOI: 10.1016/j.ijhydene.2011.01.026

[5] Y. Zhang, M. Ouyang, Q. Lu, J. Luo, X. Li. A model predicting performance of PEM fuel cell stack thermal system, Ap. Therm. Eng. 24 (2004) 501-513.

DOI: 10.1016/j.applthermaleng.2003.10.013

[6] C. Graf, A. Vath, N. Nicoloso. Modeling of the heat transfer in a portable PEFC system within MATLAB-Simulink, J. Pow. Sour. 155 (2006) 52-59.

DOI: 10.1016/j.jpowsour.2005.01.087

[7] K.P. Adzakpa. Transient air cooling thermal modeling of a PEM fuel cell, J. Pow. Sour. 179 (2008) 164-176.

DOI: 10.1016/j.jpowsour.2007.12.102

[8] Ana M. Lopez-Sabiron, J. Barroso, V. Roda, J. Barranco, A. Lozano, F. Barreras. Design and development of the cooling system of a 2 kW nominal power open-cathode polymer electrolyte fuel cell stack. Int. J. Hydrogen Energy 37 (8) (2012) 7289-7298.

DOI: 10.1016/j.ijhydene.2011.11.073

[9] W. A. N. W. Mohamed, R. Atan, Thermal and Coolant Flow Computational Analysis of Cooling Channels for Air-Cooled PEM Fuel Cell, Applied Mechanics and Materials: Mechanical and Aerospace Engineering, 110-116 (2012) 2746-2753.

DOI: 10.4028/www.scientific.net/amm.110-116.2746

[10] C.S. Spiegel, Designing and Building Fuel Cells, McGraw-Hill New York, 2007, p.99.
