Robust Control Analysis Techniques Applied to a Mini Aircraft

Abstract:

This paper presents a methodology for the development of an UAV Autopilot System, based on modeling, instrumentation and a control law, with the purpose of stabilizing the airplane attitude. Firstly, were made experimental test flights by manual control for obtaining the longitudinal model parameters using the Matlab toolbox called "System Identification Tool". The model is represented by a transfer function of the pitch angle with respect to the elevator into an open-loop system. The system is stabilized using a PD controller (derivative-proportional) tuned with poles placement method. The zero exclusion principle is used to compute the robustness margin of the closed-loop system. Different experiments were made in order to validate theoretical results which are presented at the end of this work.

• Periodical: Applied Mechanics and Materials (Volume 394)
• Pages: 427-434
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.394.427
• Online since: September 2013
• Authors: R. Ibarra, W. Rodríguez, S. Florida, Gerardo Romero, D. Lara, C. Pegard, R. Abdelhamid
• Keywords: Aircraft, Autopilot, Mechatronics, Nonlinear System, Robust Control, Unmanned Aerial Vehicle (UAV)

References

[1] R. Austin, Unmanned Aircraft Systems: UAVS Design, Development and Employment, Wiley, (2010).

[2] R. Ibarra, R. Dominguez, D. Lara, G. Romero and C. Pegard, Ground station design for a UAV monitoring, Proceeding of the 2nd international congress on instrumentation and application sciences, October, 2011, Puebla, Puebla Mexico.

[3] Z. Taha, Y.R. Tang and K.C. Yap, Development of an onboard system for flight data collection of a small-scale UAV helicopter, Mechatronics, Vol. 21, pp.132-144.

DOI: 10.1016/j.mechatronics.2010.09.008

[4] System Identification Toolbox user guide, Math works, available at: http: /www. mathworks. cn/help/pdf_doc/ident/ident. pdf (Accessed on July 2012).

[5] Chen-Tsong Chen, Lineal System Theory and Design, Oxford University Press, (1999).

[6] B.L. Stevens and F.L. Lewis, Aircraft Control and Simulation, John Wiley and Sons, (2003).

[7] B. Etkin and L. D. Reid, Dynamics of Flight Stability and Control, John Wiley and Sons, (1996).

[8] J. Roskam, Airplane Flight Dynamics and Automatic Flight Controls, DAR corporation, (1995).

[9] N. Kannan et M. Seetharama Bhat, Longitudinal H∞ Stability Augmentation System for a Thrust-Vectored Unmanned Aircraft, AIAA-JGCD, Vol. 28, No. 6, page 1240.

DOI: 10.2514/1.12821

[10] K.J. Astrom and T. Hägglud, PID Controllers: Theory, Design and Tuning, Instrument Society of America, (1995).

[11] Barmish. B. R. New tools Robustness of Linear Systems, Macmillan Publishing Company USA, (1994).

[12] D. Lara, G. Romero, A. Sanchez, R. Lozano and A. Guerrero, Robustness Margin for Attitude of a Four Rotor Mini-Rotorcraft: Case of Study, Mechatronics, Vol. 20, No. 1, pp.143-152, February (2010).

DOI: 10.1016/j.mechatronics.2009.11.002
