The Study of Thread Parameter Based on Machine Vision for Automatic Measurement

Abstract:

In order to improve the measurement accuracy of thread parameter and can realize the automatic measurement of parameter, this paper propose a non-contact measuring method which is based on machine vision, we use the industrial linear array CCD with high-precision scan the projection of the thread which in the field of parallel light, using the image recognition, image acquisition, image data processing technology enable your computer finish the pitch diameter, thread pitch, tooth type angle on a non-contact of real-time, on-line measurement. This article also provides detailed measuring method with the main parameters of thread.

• Periodical: Applied Mechanics and Materials (Volumes 401-403)
• Pages: 1158-1161
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.401-403.1158
• Online since: September 2013
• Authors: Jing Chao, Zhan Feng Liu, Yan Shu Liu
• Keywords: Image Processing, Machine Vision, Measurement Method, Thread Parameter

References

[1] Shaowei. Shen, Shuhua. Yan, Jiping Lei: Manufacturing Technology and Machine Tool. No. 4 (2010), pp.96-99.

[2] Chen Bu, Peng Wan: Industrial Instrumentation and Automation. No. 3 (2011), pp.83-85.

[3] PingbinYuan, Zongming. Yuan: Pipeline Technique and Equipment. No. 4 (2008), pp.20-22.

[4] GuangZhu, XueFang. Zhu: Computer and Digital Engineering. Vol. 38No. 11 (2010), pp.156-159.

[5] Xingfu. Liu: Research and Development. (2012), pp.045-049.
