Moving Grid Method for Simulating Crack Propagation

Abstract:

A moving grid nonlinear finite element method was used in this study to simulate crack propagation. The relevant elements were split along the direction of principal stress within the element and thus automatic optimization processing of local mesh was realized. We discussed the moving grid nonlinear finite element algorithm was proposed, compiled the corresponding script files based on the dedicated finite element language of Finite Element Program Generator (FEPG), and generate finite element source code programs according to the script files. Analyses show that the proposed moving grid finite element method is effective and feasible in crack propagation simulation.

• Periodical: Applied Mechanics and Materials (Volumes 405-408)
• Pages: 3173-3177
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.405-408.3173
• Online since: September 2013
• Authors: Shu Feng Xu*, Huai Fa Ma, Yong Fa Zhou
• Keywords: Crack Propagation, Finite Element Method (FEM), Moving Grid Method, Numerical Simulation

References

[1] Yang Wei. Macro and micro fracture mechanics [M]. Beijing: National Defense Industry Press(1995). (in Chinese).

[2] Liang guoping, Zhou Yongfa. Finite element language and its application. Beijing: Science Press, (2013). (in Chinese).

[3] Beijing FEGEN Software Co., Ltd. FEPG6. 0 technical descriptions(2009). (in Chinese).

[4] Tang Chunan, Zhu Wancheng. Concrete damage and fracture-numerical experiments. Beijing: Science Press, (2003), pp.24-122. (in Chinese).

[5] MA Huaifa, CHEN Houqun, LI Baokun. Influence of strain rate effect on dynamic bending strength of concrete [J]. Journal of hydraulic engineering, (2005), Vol. 36(1): pp.69-76. (in Chinese).
