An Improved Expert Intelligent PID Control in Maglev Transportation System with Different Track Irregularities

Abstract:

Track irregularity is one of the most important aspects of the suspension control performance impact in Magnetic Transportation System (MTS). By using the traditional PID control, the problem was that it was difficult to confirm the PID parameters and have long settling time, even appear the chaotic phenomenon. However, using Expert PID(EPID) control method producesd over-fitting to initial assignments, local optimum induced easily and slow convergence rate problem. Based on the global optimization feature of PSO algorithm, it had been adopted to optimize the initial values of Expert PID control. An intelligent control algorithm for the maglev transportation system was put forward based on Expert PID optimized by Particle Swarm Optimization algorithm (EPID-PSO). The expert rule was that if the absolute value of the error trended to decrease, the PID current control keeped its maintenance; if not, then the PID current control applied strong functions. Under this rule, the dynamic error was reduced and the performance of track irregularity was improved. Simulation results by MATLAB proves that the control scheme has good robustness, shorter adjustment time, faster response time, achieving better quality of control under the three conditions of step signal, low frequence sine wave signal and high frequence square wave signal.

• Periodical: Applied Mechanics and Materials (Volumes 409-410)
• Pages: 1141-1146
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.409-410.1141
• Online since: September 2013
• Authors: Rong Rong Song, Wei Hua Ma, Zi Li Chen
• Keywords: Expert PID Control, Maglev Transportation System, MATLAB Simulation, PSO Algorithm, Track Irregularity

References

[1] Hongyi Li, Jinyong Yu, Hilton C., Honghai Liu. Adaptive Sliding-Mode Control for Nonlinear Active Suspension Vehicle Systems Using T-S Fuzzy Approach[J]. Industrial Electronics. Vol. 60, (2013), pp.3328-3338.

DOI: 10.1109/tie.2012.2202354

[2] Ma, Weihua, Song Rongrong. Analyses of the Additional Stiffness Function of the Traction Bar on the Vertical Dynamics Performance of Subway Vehicle[J]. PRZEGLAD ELEKTROTECHNICZNY, 88(1B), (2012), pp.39-43.

[3] Weihua Ma, Shihui Luo, Rongrong Song. Coupler dynamic performance analysis of heavy haul locomotives[J]. Vehicle System Dynamics, Vol. 8, (2012), pp.1-18.

DOI: 10.1080/00423114.2012.667134

[4] Hengkun Liu, Xiao Zhang, Wensen Chang. PID Control to Maglev Train System[C]. Industrial and Information Systems. (2009), pp.341-343.

[5] Shing-Jen Wu, Cheng-Tao Wu, Yen-Chen Chang. Neural-Fuzzy gap control for a Current/Voltage-controlled 1/4-vehicle maglev system [J]. Intelligent Transportation Systems. Vol. 9, (2008), pp.122-136.

DOI: 10.1109/tits.2007.911353

[6] Wen Yu and Jacob Rosen. Neural PID Control of Robot Manipulators With Application to an Upper Limb Exoskeleton[J]. CYBERNETICS. Vol. 43, No. 2, (2013), pp.673-684.

DOI: 10.1109/tsmcb.2012.2214381

[7] Haitao Wang and Heming Jia. Study of Immune PID Controller for Wood Drying System[C]. Communication Systems and Network Technologies. (2013), pp.827-831.

DOI: 10.1109/csnt.2013.176

[8] Li Huirong, Zhang Xuefeng, Pang Lijuan and Deng Gang. The temperature controlling system design of ARP during cold rolling based on expert system[C]. Intelligent Computation Technology and Automation. (2012), 368-370.

DOI: 10.1109/icicta.2012.98

[9] Rong-Jong Wai, Jeng-Dao Lee, Kun-Lun Chuang. Real-Time PID Control Strategy for Maglev ransportation System via Particle Swarm Optimization[J]. Industrial Electronics. Vol. 58, pp.629-646 Communications and Networks. (2011), pp.5315-5319.

DOI: 10.1109/tie.2010.2046004

[10] Yunde Xie, Wensen Chang. Electromagnetic (EMS) Modeling and Simulation of Maglev Train System in Vertical Direction . Journal of the China Railway Society. Vol. 4, (1996), pp.47-54 (In Chinese).

[11] Anet Neto L., Erasme D., Genay N., Chanclou P., Deniel, Q., Traore, F., Anfray, T., Hmadou, R. Simple Estimation of Fiber Dispersion and Laser Chirp Parameters Using the Downhill Simplex Fitting Algorithm. Lightwave Technology. Vol. 31, (2013).

DOI: 10.1109/jlt.2012.2226704

[12] Henss, T., Huning, D., Kersten, S., Maetting, P., Mechtel, M., Wulff, N. Pixel Advisor: An Expert System for the ATLAS Pixel Detector Control System. Nuclear Science. Vol. 60, (2013), pp.1265-1271.

DOI: 10.1109/tns.2012.2216290

[13] Behbahani, S., de Silva, C.W. Mechatronic Design Evolution Using Bond Graphs and Hybrid Genetic Algorithm With Genetic Programming. Mechatronics. Vol. 18, (2013), pp.190-199.

DOI: 10.1109/tmech.2011.2165958

[14] Li Li, Niu Ben. Particle swarm optimization algorithm. Beijing: Metallurgical Industry Press. 2009(In Chinese).
