Synthetic Boundary Conditions for Analytical Magnetic Field Analysis of Halbach Magnet Arrays

Abstract:

This paper presents a kind of synthetic boundary conditions for the analytical magnetic field analysis of Halbach magnet array, which are derived from the linear demagnetization characteristic and the equivalent surface current of permanent magnet (PM). With the proposed synthetic boundary conditions, boundaries of Halbach PM array are simplified to only two surfaces. As a result, a relatively simple analytical solutions of Halbach magnetization topology based on the magnetic scalar potential (MSP) are obtained.

• Periodical: Applied Mechanics and Materials (Volumes 416-417)
• Pages: 373-378
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.416-417.373
• Online since: September 2013
• Authors: He Yun Lin, Ping Jin, Shu Hua Fang
• Keywords: Halbach Magnet Array, Magnetic Scalar Potential (MSP), Synthetic Boundary Conditions

References

[1] Z. Q. Zhu, Recent development of Halbach permanent magnet machines and applications, in Proc. Power Conversion Conf. Nagoya, Japan, Apr. 2007, pp. K9-K16.

DOI: 10.1109/pccon.2007.372911

[2] K. Halbach, Design of permanent magnet multipole magnets with oriented rare earth cobalt material, Nucl. Instrum. Meth., vol. 169, no. 1, pp.1-10, Feb. (1980).

DOI: 10.1016/0029-554x(80)90094-4

[3] Y. Amara and G. Barakat, Analysis of magnetic field distribution of a cylindrical discrete halbach permanent magnet linear generator, IET Electr. Power Appl., Vol. 4, no. 8, pp.629-636, Sep. (2010).

DOI: 10.1049/iet-epa.2009.0267

[4] M. Marinescu and N. Marinescu, New concept of permanent magnet excitation for electrical machines. Analytical and numerical computation, IEEE Trans. Magn., vol. 28, no. 2, pp.1390-1393, Mar. (1992).

DOI: 10.1109/20.123952

[5] D. L. Trumper, W. J. Kim, and M. E. Williams, Design and analysis framework for linear permanent-magnet machines, IEEE Trans. Ind. Appl., vol. 32, no. 2, pp.371-379, Mar. /Apr. (1996).

DOI: 10.1109/28.491486

[6] K. Atallah and D. Howe, The application of Halbach cylinders to brushless AC servo motors, IEEE Trans. Magn., vol. 34, no. 4, pp.2060-2062, Jul. (1998).

DOI: 10.1109/20.706795

[7] M. G. Lee, S. Q. Lee, and D. G. Gweon, Analysis of Halbach magnet array and its application to linear motor, Mechatronics, vol. 14, no. 1, pp.115-128, Feb. (2004).

DOI: 10.1016/s0957-4158(03)00015-1

[8] Z. P. Xia, Z. Q. Zhu, and D. Howe, Analytical Magnetic Field Analysis of Halbach Magnetized Permanent-Magnet Machines, IEEE Trans. Magn., vol. 40, no. 4, pp.1864-1872, Jul. (2004).

DOI: 10.1109/tmag.2004.828933

[9] J. B. Wang and D. Howe, Tubular modular permanent-magnet machines equipped with quasi-Halbach magnetized magnets-part I: magnetic field distribution, EMF, and thrust force, IEEE Trans. Magn., vol. 41, no. 9, pp.2470-2478, Sep. (2005).

DOI: 10.1109/tmag.2005.854328

[10] J. B. Wang, D. Howe, and G. W. Jewell, Fringing in tubular permanent-magnet machines: Part I. Magnetic field distribution, flux linkage, and thrust force, IEEE Trans. Magn., vol. 39, no. 6, pp.3507-3516, Nov. (2003).

DOI: 10.1109/tmag.2003.819463
