The Simulation of Heat Pipe Evaporator in Concentration Solar Cell

Abstract:

Considering the problem of the concentrating solar cell efficiency restricted by the temperature. The closed two-phase thermosyphon was used to dissipation heat in concentrating solar cell at high heat flux, which adopted water as the working fluid. The temperature distribution of evaporator had significant effect on solar cell performance and heat pipe efficiency. A numerical simulation model of evaporator was established by FLUENT. During the computing process, the heat flux, filling ratio of liquid and saturation temperature were taken into account. It was found that the maximum temperature of evaporator was less than 85°C, when the solar cell operated in 140 to 180 suns, in the conditions of evaporator size (Length×Width×Height, 100×100×30 mm), the optimum charging ratio of liquid is between 27%～30%. The smaller saturation temperature would bring the better heat transfer characters.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 1207-1212
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.1207
• Online since: December 2010
• Authors: Zi Long Wang, Hua Zhang, Hai Tao Zhang
• Keywords: Closed Two-Phase Thermosyphon, Concentration, Solar Cell

References

[1] Mary D A , Robert H. Clean electricity from photovoltaics [M]. London: Imperial College Press , (2001).

[2] Ma Shijun. Power Technology of Satellites (in Chinese) [M]. Beijing: Space Navigation Press , (2001).

[3] Ran Y Kim. Dimensional stability of composite in a space thermal environment [J] . Composites Science and Technology , 2000 , 60 : 2601－2608.

DOI: 10.1016/s0266-3538(00)00052-x

[4] Wang Sicheng. Review and Trend of solar photovoltaic technology [J]. International Power , 2006 (4) : 21－23.

[5] Li Junfeng, Wang Sicheng, Zhang Minji, Ma Lingjuan. 2007 . The report of the Chinese photovoltaic's development. Beijing: China Environmental Science Press.

[6] Ghassan Zubi, José L. Bernal-Agustín, Gian Vincenzo Fracastoro. High concentration photovoltaic systems applying III—V cells. Renewable and Sustainable Energy Reviews. 2009: 2645－2652.

DOI: 10.1016/j.rser.2009.07.002

[7] Weng Zhengjun , Yang Honghai . Application of several kinds of cooling technology in the concentrator photovoltaic cells. Energy Technology . 2008 (1): 16-18.

[8] Tao Wenquan. Numerical Heat Transfer (the second edition). Xi an: Xi'an Jiaotong University Press, (2001).

[9] The International Association for the Properties of Water and Steam. Germany. (1997).

[10] Liu Zhigang, Liu Xianding, Zhao Guanchun. Application and compilation of calculation program in working medium's thermophysical properties. Beijing: The Science Press, (1992).
