Electromagnetic Interference’s Effect on the Performance of Electro-Hydraulic Control System

Abstract:

The performance of engineering machinery and equipments will be affected under the environment of unstable electromagnetic fields. In the magnetic field, with focusing on the proportional solenoid of a certain engineering machinery hydraulic proportional control system, the internal changes of characteristics in the magnetic field lead to the changes of force output characteristics through output changes in air gap magnetic flux, and the instantaneous output performance is affected by electromagnetic interference. The electromagnetic environment’s effect on the changes of electro-hydraulic control system is determined by implementation of the proportional solenoid electromagnetic interference. The result shows that the control performance of mechanical hydraulic control system becomes unstable, and the anti-electromagnetic interference capacity of electromagnetic sensitive element in the electro-hydraulic control system should be improved.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 1218-1222
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.1218
• Online since: December 2010
• Authors: Kai Zhang, Wan Li Li, Jian Li, Zhang Ping You
• Keywords: Engineering Machinery, Hydraulic System, Proportional Solenoid

References

[1] Wu Genmao, Qiu Minxiu, Wang Qingfeng, et al, eds. Electrohydraulic proportional technique in theory and application[M]. Hang zhou: Zhejiang University Press, (2006).

[2] YU Zhaofeng, YU Ying, XU Mingqian. Overview on Automotive EMC Research at Home and Abroad[J]. Bus Technology and Research, 2 (2007), pp.8-10.

[3] Cui Hongmin, Chen Guanjun, Dong Jiaguo, et al. EMC design of pressure sensors[J] Journal of Transducer Technology, 6 (2004), pp.27-29.

[4] Li Qipeng, Ding Fan, Wang Chuanli. Study of high pressure bi_directional proportional solenoid [J]. Journal of Zhejiang University: Engineering Science, 2 (2006), pp.322-325.

[5] Zhang Kai，Li Wanli， et al. Effect of Electromagnetic Environment on the Performance of Electric Proportional Variable-capacity Pump[J] . KEJI DAOBAO, 5 (2010), pp.91-95.

[6] Zhang Kai, Li Wanli, Chen Xiwei. Study on the biconical antenna in the EMC test suitable for engineering machinery[C]/Proceedings of the International Conference on Electromagnetic Interference and Compatibility，IEEE, (2009), pp.274-279.

DOI: 10.1109/csie.2009.284

[7] You Zhangping, Lai Lei, Li Wanli. CAN bus based on the continuous wall grab crane Data Acquisition System[J]. Chinese Journal of Construction Machinery, 6(2009), pp.171-174.
