Three-Dimension Reconstruction of Pit Corrosion Damage Morphology and Digital Simulation

Abstract:

According to the various grey values at different regions in an image, a three-dimension (3D) solid model is reconstructed based on the pitting corrosion damage data obtained from the pre-corrosion accelerated experiment which is performed under four different time levels: 12h, 24h, 48h and 72h by CAD. An analysis procedure is developed using finite element analysis to predict stresses and the crack nucleation site due to corroded pits. Based on the observations on fatigue fracture section, the AFGROW software is used to simulate the influence of a variety of corrosion damages and corrosion pit depths on the specimen’s residual fatigue life. An effective and reliable engineering method for predicting fatigue life of corroded specimen is established on the base of this research work.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 4186-4190
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.4186
• Online since: December 2010
• Authors: Sheng Li Lv, Zhen Guo Wang, Cheng Long Xu, Wei Zhang
• Keywords: Finite Element Model (FEM), Pitting Corrosion, Pre-Corrosion, Residual Fatigue Life Prediction

References

[1] Chen Yueliang, Lv Guozhi, Duan Chengmei: Acta Aeronautica et Astronautica Sinica Vol. 23 (2002), p.2249.

[2] Alyousif O M: Corrosion and corrosion fatigue of aluminum alloys [D]. USA: Lehigh University, (2002).

[3] Harlow D J, Wei R P. Engineering Fracture Mechanics Vol. 59 (1998), p.305.

[4] American Society for Testing and Materials, U.S. ASTM G34-01(2007).

[5] American Society for Testing and Materials, U.S. ASTM G1-90 (1999).

[6] Horn B, Brooks M. Computer Vision: Graphics and Image Processing Vol. 33 (1986), p.174.

[7] DuQuesnay D L，Underhill P R，Britt H J: International Journal of Fatigue Vol. 25 (2003), p.371.
