Outer Conductor Inner Diameter Measuring System of Coaxial Transmission Line

Abstract:

In this paper, an outer conductor diameter measuring system for coaxial transmission lines are introduced. The structure of pole-distance changing cylinder capacitor sensor probe aperture measuring is analyzed. The signal analysis and control system of the whole measurement system is introduced in detail. The guarding ring technology is used to eliminate edge effect of effective measuring sensor electrode. The operation amplifying transform circuit is used to overcome the nonlinear problem of pole-distance changing sensor. Driving cable technology is adopted to reduce the influence of parasitic capacitance. Through the CCD image centering and grating encoder driven by stepping motor drive system and encoder system X, Y, Z axis precision positioning, in order to realize the long hole in any section of the nanomeasuring diameter; The measuring types of this system is: Φ 0.8 mm, Φ 1 mm, Φ 1.8 mm to Φ 7 mm hole diameter. The resolution is 5nm--20nm, the standard deviation of repeated measurement is 0.05μm--0.1μm. The measurement uncertainty is 2μm0.2μm.

• Periodical: Applied Mechanics and Materials (Volume 440)
• Pages: 147-152
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.440.147
• Online since: October 2013
• Authors: Hong Yu Ye, Yi Zhong Zheng*
• Keywords: Automatic Control Model, Capacitive Sensing, CCD Image Centering, Inner Diameter of Long Hole, Nano-Measurement, Signal Processing

References

[1] MA Zhen-Yu, MA Guang-Ming, HOU Hong-Tao, Evaluation of external quality factor of the superconducting cavity using extrapolation method, Nuclear Science and Techniques, 2009. 20 (2) 65~67.

[2] Stone J. Muralikrishnan B. Geometric Effects When Measuring Small Holes With Micro Contact Probes, Journal of Research of the National Institute of Standards and Technology, 2011, 116 (2) : 573-587.

DOI: 10.6028/jres.116.006

[3] Hrioshi MURAKAMI, Akio KATSUKI, Hiromichi ONIKURA. Development of a system for measuring micro hole accuracy using an optical fiber probe, Journal of Advanced Mechanical Design, Systems and Manufacturing, 2010, 4 (5) : 995-1004.

DOI: 10.1299/jamdsm.4.995

[4] Han Ki-Ho, Cho Young-Ho. Self-balanced high-resolution capacitive micro accelerometers using branched finger electrodes with high-amplitude sense voltage. 15th IEEE International Conference on Micro Electro Mechanical Systems MEMS, 2002, pp.714-717.

DOI: 10.1109/memsys.2002.984370

[5] L.K. Gillespie, J.W. Graham, Miniature machining-Part5, Tolerances and Techniques of Miniature Hole Measurement, Machine and Tool Blue Book, (1999).

[6] Yu Yongxin, Zhang Heng, Wang Zongchao, Chang Yizhe. Deep-hole inner diameter measuring system based on non-contact capacitance sensor, Transactions of Tianjin University, 2010, 16 (6) : 447-451.

DOI: 10.1007/s12209-010-1452-9

[7] Yu Yong-Xin, Zhang Heng, Chang Yi-Zhe. Study of Deep-hole Aperture Measurement Management System Based on Capacitance Sensor, 8th International Symposium on Test Measure, 2009, Vol. 1: 1807-1811.

[8] Xu SX, Guo H, Wang BG. Field inspection system of aperture of small blind holes in the machining process, 3rd International Symposium on Instrumentation Science and Technology, 2004, Vol. 1: 1264-1268.

[9] Wu Xiao-feng, ZHANG Guo-xiong. Development of a Modern Coordinate Measuring Machine, Nanotechnology and Precision Engineering, 2006, 4 (4) : 301-306.

[10] Sun Chang-kun, Wang Xiao-bing, Liu Bin, Zheng Yi-zhong. Tiny aperture measurement by capacitance sensor．Nanotechnology and precision engineering, 2006, 02(4): 30-32.

[11] Wang Bao-Guang, Zhang Heng, Qian Zheng-yu, Zheng Yi-zhong. The research on accurate measuring of blind hole depth, Measurement journal, 2006, 27 (3) : 228-231.

[12] Zhou Xin-lin, Yu Zhan-guo, Zheng Yi-zhong. The research on small deep hole diameter measurement by capacitive sensor. The Chinese mechanical engineering, 2007, 18 (21): 2535-2538.

[13] Guo Hui, Zhou Xing-lin, Liu Shu-gui, Sun Chang-ku, Zheng Yi-zhong. The research on measurement system of adjacent hole wall and small blind hol. Instruments journal, 2003, Vol. 24, (4) : 185-187.

[14] Li Ya-biao, Wang Bao-guang, Feng Xiao-qiang. The research on High precision hole-aperture automatic measurement system by capacitive sensor. Sensor and micro system, 2009, Vol. 28 (12) : 14-16.
