8-Way Substrate Integrated Waveguide Power Divider
p.137

Arbitrary Integer Frequency Divider Based on Single Chip Microcomputer
p.141

Transmission Characteristic Analysis of PD Signal in Power Cable
p.146

Heat Pipe Cooling Scheme Analysis of Injection Molding Machine Controller
p.150

A Novel Triple-Band Monopole Antenna for WLAN/WiMAX/RFID Applications
p.154

HomeApplied Mechanics and MaterialsApplied Mechanics and Materials Vol. 4418-Way Substrate Integrated Waveguide Power Divider

8-Way Substrate Integrated Waveguide Power Divider

Abstract:

In this Paper, a 8-way Microwave Equal Power Divider with Substrate Integrated Waveguide Technology is Proposed and Designed . the Substrate Integrated Waveguide Power Divider with Metal pin Inductance is Investigated and Simulated. the Center Frequency is 9.5GHz, and the Operating Frequency Band is more than 1GHz. the Maximal Insert Loss is Less than 1dB from 9GHz to 10GHz. the Impedance of each Ports is 50Ω.
