Arbitrary Integer Frequency Divider Based on Single Chip Microcomputer

Abstract:

Arbitrary integer frequency divider based on single chip microcomputer proposed an arbitrary integer frequency divider design scheme within 100 for digital clock signals. Microcontroller detected the parity of the points frequency which was inputted by the external keyboard, and then controlled the switching controller switched the point frequency circuit between odd points frequency circuit and even. Therefore, a circuit design could solve problem along with the changing of the circuit and the heavy labor for changing the frequency num that existed in traditional divider .So it greatly reduced the cost.

• Periodical: Applied Mechanics and Materials (Volume 441)
• Pages: 141-145
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.441.141
• Online since: December 2013
• Authors: Jun Jie Lin, Chun Yang Wang, Da Sen Wang
• Keywords: Arbitrary Integer Frequency Division, Digital Circuit, Parity Frequency Division, Single Chip Microcomputer

References

[1] Y. Y. Deng and Q. Wu: Modern Electronic Technology, (2005), No. 16, p.25.

[2] H. Wang and Hong Li: Modern Electronic Technology, (2005), No. 24, p.8.

[3] Q. Y. Gao and X. C. Li: Chinese Journal of Electronics, Vol. 32 (2004), No. 5, p.869.

[4] C. Y. Hua and S. B. Tong: Basis of Analogue Electronic Technique (China Higher Education Press, China 2008).

[5] S. Yan: Basis of Digital Electronic Technique (China Higher Education Press, China 2008).

[6] T. X. Guo: 51 single-chip C language tutorial (Publish House Of Electronics Industry, China 2009).

[7] H. Q. Tan: C Language Programming (Tsinghua University Press, China 2005).

[8] Media Tek Inc: China CN 102201808 A. (2011).

[9] Ningbo University: China CN 2924932 Y. (2007).
