Heat Pipe Cooling Scheme Analysis of Injection Molding Machine Controller

Abstract:

In the long run, the problem of high temperature has been existed in a companys injection molding machine controller. In order to solve the heat dissipation problem, two kinds of heat pipe heat dissipation schemes are designed, CFD software ICEPAK is used in the report to make a numerical simulation as well as a simulation analysis of the Heat pipe cooling scheme. By comparing two kinds of cooling mode heat pipe cooling effect and structure process, Vertical-type heat pipe cooling solution that meets the cooling requirements and makes heat-sensitive components stay away from high-temperature, furthermore heat pipe processing technology is relatively simple.

• Periodical: Applied Mechanics and Materials (Volume 441)
• Pages: 150-153
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.441.150
• Online since: December 2013
• Authors: Jing Long, Bing Bing Chen, Chun Liang Zhang, Liang Liang Zhang
• Keywords: Heat Pipe, ICEPAK Software, Simulation, Thermal Design

References

[1] C.T. Qiu, D.S. Zhao and Q.X. Jiang: Electronic Device Structure Design Principles[M] Nanjing: Southeast university press (2005).

[2] C.Y. Yu: Computer-Aided Electronic Equipment Thermal Analysis, Thermal Design and Thermal Testing Technology Research[D] Beijing: Beijing University of Aeronautics and Astronautics (2000).

[3] Z.D. Fang, G.C. Fu and Z.X. Gao: Electronic Equipment Thermal Analysis Software Application Research [J]. Journal of Beijing University of Aeronautics and Astronautics, 2003 (8): 737-740.

[4] J.H. Xiang, C.L. Zhang and F. Jiang: Thermal Columnar Structure Convective Heat Transfer Process Simulation and Optimization Research [J]. Journal of Guangzhou University, 2012, 11 (3): 81-85.

[5] Tuckerman D B, Pease R F W. High-Performance Heat Sinking for VLSI[J]. Electron Device Letter, 1981, 2 (5): 126-129.

DOI: 10.1109/edl.1981.25367
