Finite Element Analysis and Simulation of the Sealing Performance of Y-Ring Rubber Seal

Abstract:

Application of super elasticity theory and nonlinear theory, based on finite element method and the Abaqus software, the performance of Y ring rubber seal, such as the Von Mises stress, the sealing ring deformation and the contact pressure were simulated and analyzed under the influence of changeable hydraulic pressure. According to seal failure criterion, the effect of hydraulic pressure changes on the sealing performance were studied. Results show that, the maximum stress appears in the intersection of lips, the largest deformation area near the inner lip. The root has greater contact pressure, which would result in bitten phenomenon or aggravate wear.

• Periodical: Applied Mechanics and Materials (Volumes 444-445)
• Pages: 1379-1383
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.444-445.1379
• Online since: October 2013
• Authors: Kai Bo Cui, Jun Qi Qin, Chang Chun Di, Yan Feng Yang
• Keywords: Acrylonitrile Butadiene Rubber, Changeable Hydraulic Pressure, Constitutive Model, Nonlinear Finite Element Analysis, Y-Ring Rubber Seal
