Equivalent Modeling of Large-Scale Photovoltaic Power Plant

Abstract:

This paper introduces the single unit model of photovoltaic (PV) system as the basic component for the modeling of the large-scale PV power plant. Based on the single unit model, the equivalent models of the large-scale PV power plant are presented in two different situations. As the general situation of the two in which the parameters of the inverter controllers are different, a clustering and equivalent modeling method based on the characteristic distance of parameter sensitivity is proposed. Finally, the simulation cases are provided to verify the effectiveness of the equivalent models.

• Periodical: Applied Mechanics and Materials (Volumes 448-453)
• Pages: 1419-1422
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.448-453.1419
• Online since: October 2013
• Authors: Yuan Chai*, Jing Hong Zheng, Lian Shu, Shou Zhen Zhu
• Keywords: Characteristic Distance, Clustering Method, Equivalent Model, Large-Scale Photovoltaic Power Plant, Modeling Method

References

[1] Zhengming Zhao, Yi Lei, Fanbo He, et al. Overview of large-scale grid-connected photovoltaic power plants [J]. Automation of Electric Power Systems, 2011 35(12) : 101-107(in Chinese).

[2] Xiuyuan Yang, Xiaohe Liu, Fang Zhang, et al. Model of large PV and its applications on power system analysis[J]. Proceedings of CSEE, 2011 31(12): 19-22. (in Chinese).

[3] H. Patel and V. Agarwal, Maximum power point tracking scheme for PV systems operating under partially shaded conditions, IEEE Trans. on Industrial Electronics, 2008 55(4): 1689 – 1698.

DOI: 10.1109/tie.2008.917118

[4] Xiaoyan Liu , Xinmei Qi, Shousen Zheng, et al. Model and analysis of photovoltaic array under partial shading[J]. Journal of System Simulation, 2012, 24(5): 1125-1131. (in Chinese).

[5] L.M. Fernández, C.A. García, J.R. Saenz, F. Jurado, Equivalent models of wind farms by using aggregated wind turbines and equivalent winds, Energy Conversion and Management, 2009 vol. 50 : 691~704.

DOI: 10.1016/j.enconman.2008.10.005

[6] Jianfeng Sun, Lianwei Jiao, Junling Wu, et al. Research on multimachine dynamic aggregation in wind farm[J]. Power System Technology, 2004 28(7): 58-61. (in Chinese).

[7] Cueumo M, Rosa A D, Ferraro V, et al. Performance analysis of a 3kW grid-connected photovoltaic plant [J]. Renew able Energy, 2006, 31(8): 1129-1138.

DOI: 10.1016/j.renene.2005.06.005

[8] Schonardie M F，Martins D C. Application of the dq0 transformation in the three-phase grid-connected PV systems with active and reactive control[C]. Proceedings of 2008 International Conference on Sustainable Energy Technologies. Singapore: IEEE, 2008: 18-23.

DOI: 10.1109/icset.2008.4746965
